OEM#: C322BNew OEM Original Outright

EXPLOSION PROOF MOTOR, C322A, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors

Your price:
$1,047.83 eachEstimated to ship by 05/07 if ordered before 10:30 AM EST
HomeMarathon Motorsc322b
EXPLOSION PROOF MOTOR, C322A, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
EXPLOSION PROOF MOTOR, C322A, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors

OEM#: C322B
EXPLOSION PROOF MOTOR, C322A, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors

New OEM Original Outright
Your price:
$1,047.83 each
Estimated to ship by 05/07 if ordered before 10:30 AM EST
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

Marathon Motors Explosion Proof Motor, C322A, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC

Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.

Technical Specs
P/N: C322B Key Specs
Item
EXPLOSION PROOF MOTOR, C322A, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
C322B
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
5.2/2.6
50 Hertz Fl Eff
82.5
50 Hertz Hp
1.5
50 Hertz Kw
1.12
50 Hertz Rpm
1500
50 Hertz Sf
1.15
50 Hertz Voltage
190/380
60 Hertz Kw
1.492
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
205
Ce
N
Country of Origin
USA
Csa
N
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
6-5.6/2.8
Fl Efficiency
84
Frame
145TC
Hazardous Location
EXP PROOF CL I GR D CL II GR F&G T3B
Hertz
60/50
Horsepower
2
Insulation Class
F
Ip Code
54
Is_Motor
Yes
Kva-Code
K
Model Number
145TTGN4338
Motor Rpm 50Hz
1500
Motor Rpm 60Hz
1800
Mounting
C-Face Footless
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Across the Line
Thermal Protection
Not Thermostats (Normally Closed)
Ul
UL Listed
Voltage
208-230/460
Weight
76
