OEM#: G661New OEM Original Outright

EXPLOSION PROOF MOTOR, 56T17G5313, 3/4HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors

Your price:
$697.71 eachShip date will be provided after ordering
EXPLOSION PROOF MOTOR, 56T17G5313, 3/4HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
EXPLOSION PROOF MOTOR, 56T17G5313, 3/4HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors

OEM#: G661
EXPLOSION PROOF MOTOR, 56T17G5313, 3/4HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors

New OEM Original Outright
Your price:
$697.71 each
Ship date will be provided after ordering
Asset Information
Are you an existing customer? Sign in to access your account.
Product Overview

Marathon Motors Explosion Proof Motor, G661, 56T17G5313, 3/4HP, 208-230/460V, 1800RPM, 3PH, EPFC

Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.

Technical Specs
P/N: G661 Key Specs
Item
EXPLOSION PROOF MOTOR, 56T17G5313, 3/4HP, 208-230/460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
G661
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.56
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
2.9-3.0/1.5
Frame
56
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
3/4
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
L
Model Number
56T17G5313
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Across the Line
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
208-230/460
Weight
30
