OEM#: I514New OEM Original Outright
EXPLOSION PROOF MOTOR, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
Your price:
$1,596.81 each
OEM#: I514EXPLOSION PROOF MOTOR, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$1,596.81 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, I514, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: I514 Key Specs
Item
EXPLOSION PROOF MOTOR, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
I514
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
1.49
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6205
Ce
N
Country of Origin
USA
Csa
N
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
6.2-6/3
Fl Efficiency
86.5
Frame
145T
Hazardous Location
"EXP PROOF CL I GR C&D CL II GR E,F,G T3B"
Hertz
60
Horsepower
2
Insulation Class
F
Ip Code
54
Is_Motor
Yes
Kva-Code
L
Model Number
145TTGR16040
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Across the Line
Thermal Protection
Thermostats (Normally Closed)
Ul
UL Listed
Voltage
208-230/460
Weight
55
Marathon Motors Explosion Proof Motor, I514, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
