OEM#: G827New OEM Original Outright
EXPLOSION PROOF MOTOR, 056T17E5310, 1/4HP, 208-230/460V, 1800RPM, 3PH, EPNV by Marathon Motors
Your price:
$588.72 each
OEM#: G827EXPLOSION PROOF MOTOR, 056T17E5310, 1/4HP, 208-230/460V, 1800RPM, 3PH, EPNV by Marathon Motors
New OEM Original Outright
Your price:
$588.72 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, G827, 056T17E5310, 1/4HP, 208-230/460V, 1800RPM, 3PH, EPNV
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: G827 Key Specs
Item
EXPLOSION PROOF MOTOR, 056T17E5310, 1/4HP, 208-230/460V, 1800RPM, 3PH, EPNV
OEM
Marathon Motors
OEM #
G827
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.19
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Fl Amps
1.1-1.1/.55
Frame
56C
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
1/4
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
M
Model Number
056T17E5310
Motor Rpm 60Hz
1800
Mounting
C-Face Footless
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Across the Line
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
208-230/460
Weight
25
