OEM#: G828New OEM Original Outright

EXPLOSION PROOF MOTOR, 056T17E5311, 1/3HP, 208-230/460V, 1800RPM, 3PH, EPNV by Marathon Motors

Your price:
$639.96 eachEstimated to ship by 04/03 if ordered before 10:30 AM EST
HomeMarathon Motorsg828
EXPLOSION PROOF MOTOR, 056T17E5311, 1/3HP, 208-230/460V, 1800RPM, 3PH, EPNV by Marathon Motors
EXPLOSION PROOF MOTOR, 056T17E5311, 1/3HP, 208-230/460V, 1800RPM, 3PH, EPNV by Marathon Motors

OEM#: G828
EXPLOSION PROOF MOTOR, 056T17E5311, 1/3HP, 208-230/460V, 1800RPM, 3PH, EPNV by Marathon Motors

New OEM Original Outright
Your price:
$639.96 each
Estimated to ship by 04/03 if ordered before 10:30 AM EST
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

Marathon Motors Explosion Proof Motor, G828, 056T17E5311, 1/3HP, 208-230/460V, 1800RPM, 3PH, EPNV

Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.

Technical Specs
P/N: G828 Key Specs
Item
EXPLOSION PROOF MOTOR, 056T17E5311, 1/3HP, 208-230/460V, 1800RPM, 3PH, EPNV
OEM
Marathon Motors
OEM #
G828
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.25
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Country of Origin
USA
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Fl Amps
1.3-1.2/.6
Frame
56C
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
1/3
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
J
Model Number
056T17E5311
Motor Rpm 60Hz
1800
Mounting
C-Face Footless
Nema Design
No Design Code
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Across the Line
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
208-230/460
Weight
25
