OEM#: Y603New OEM Original Outright
INVERTER DUTY MOTOR, 56H17E5304, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, EPNV by Marathon Motors
Your price:
$1,334.15 each
OEM#: Y603INVERTER DUTY MOTOR, 56H17E5304, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, EPNV by Marathon Motors
New OEM Original Outright
Your price:
$1,334.15 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y603, 56H17E5304, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, EPNV
For use in material handling, machine tools, crane and hoist, and other variable speed applications requiring up to 1000:1 constant torque speed range. To be in installed in hazardous environments as defined by the motor's explosion proof class and group rating.
For use in material handling, machine tools, crane and hoist, and other variable speed applications requiring up to 1000:1 constant torque speed range. To be in installed in hazardous environments as defined by the motor's explosion proof class and group rating.
Technical Specs
P/N: Y603 Key Specs
Item
INVERTER DUTY MOTOR, 56H17E5304, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, EPNV
OEM
Marathon Motors
OEM #
Y603
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
2.4/1.2
60 Hertz Kw
0.56
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F3
Bearing-Drive-End
Ball
Catalog No.
Y603
Ce
N
Country of Origin
USA
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Frame
56C
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Horsepower
3/4
Insulation Class
F
Inverter Speed Range
Constant 1000:1
Ip Code
54
Is_Motor
Yes
Kva-Code
P
Model Number
56H17E5304
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
UL Listed
Voltage
230/460
Weight In Lbs.
38
Marathon Motors Inverter Duty Motor, Y603, 56H17E5304, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, EPNV
For use in material handling, machine tools, crane and hoist, and other variable speed applications requiring up to 1000:1 constant torque speed range. To be in installed in hazardous environments as defined by the motor's explosion proof class and group rating.
For use in material handling, machine tools, crane and hoist, and other variable speed applications requiring up to 1000:1 constant torque speed range. To be in installed in hazardous environments as defined by the motor's explosion proof class and group rating.
