OEM#: E576ANew OEM Original Outright
EXPLOSION PROOF MOTOR, 75HP, 230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
Your price:
$12,486.53 each
OEM#: E576AEXPLOSION PROOF MOTOR, 75HP, 230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$12,486.53 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, E576A, 75HP, 230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: E576A Key Specs
Item
EXPLOSION PROOF MOTOR, 75HP, 230/460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
E576A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
169/84.5
50 Hertz Fl Eff
95
50 Hertz Hp
60
50 Hertz Kw
45
50 Hertz Rpm
1500
50 Hertz Sf
1.15
50 Hertz Voltage
190/380
60 Hertz Kw
56
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
314
Ce
N
Country of Origin
USA
Csa
N
Drive End Bearing Size
6314
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
174/87
Fl Efficiency
95.4
Frame
365T
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60/50
Horsepower
75
Insulation Class
F
Inverter Speed Range
Constant 2:1
Ip Code
54
Is_Motor
Yes
Kva-Code
G
Model Number
365TTGS16540
Motor Rpm 50Hz
1500
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6312
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Thermal Protection
Thermostats (Normally Closed)
Ul
UL Listed
Voltage
230/460
Weight
1150
Marathon Motors Explosion Proof Motor, E576A, 75HP, 230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
