OEM#: E2107New OEM Original Outright
PREMIUM EFFICIENCY MOTOR, 2HP, 1800RPM, 208-230/460V, 3PH, 145T FR, TEFC by Marathon Motors
Your price:
$693.75 eachEstimated to ship by 05/06 if ordered before 10:30 PM.
OEM#: E2107PREMIUM EFFICIENCY MOTOR, 2HP, 1800RPM, 208-230/460V, 3PH, 145T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$693.75 each
Ready to ShipEstimated to ship by 05/06 if ordered before 10:30 PM.
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Premium Efficiency Motor, E2107, 2HP, 1800RPM, 208-230/460V, 3PH, 145T FR, TEFC
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Technical Specs
P/N: E2107 Key Specs
Item
PREMIUM EFFICIENCY MOTOR, 2HP, 1800RPM, 208-230/460V, 3PH, 145T FR, TEFC
OEM
Marathon Motors
OEM #
E2107
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
6.8/3.4
50 Hertz Hp
2
50 Hertz Kw
1.49
50 Hertz Rpm
1500
50 Hertz Sf
1
50 Hertz Voltage
190/380
60 Hertz Kw
1.49
Ambient Temp C
40
Approval-Ce
Y
Assembly
F1 Only
Bearing-Drive-End
6205
Bearing-Opp-Drive-End
6203
Csa
Y
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
6-5.8/2.9
Fl Efficiency
86.5
Frame
145T
Horsepower
2
Insulation Class
F
Ip Code
43
Is_Motor
Yes
Kva-Code
L
Model Number
145TTFR16035
Motor Rpm 60Hz
1800
Mounting
Rigid
Nameplate Rpm
1800
Nema Design
B
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Across The Line
Ul
Recognized Construction
Voltage
208-230/460
Weight
49
