OEM#: E594New OEM Original Outright
EXPLOSION PROOF MOTOR, 405TTGS6548, 100HP, 230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
Your price:
$20,592.32 each
OEM#: E594EXPLOSION PROOF MOTOR, 405TTGS6548, 100HP, 230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$20,592.32 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, E594, 405TTGS6548, 100HP, 230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: E594 Key Specs
Item
EXPLOSION PROOF MOTOR, 405TTGS6548, 100HP, 230/460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
E594
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
204/102
50 Hertz Fl Eff
95.80 Percent
50 Hertz Hp
75
50 Hertz Kw
56
50 Hertz Sf
1.15
50 Hertz Voltage
190/380
60 Hertz Kw
75
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6316
Ce
N
Country of Origin
USA
Drive End Bearing Size
6316
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
226/113
Fl Efficiency
95.4
Frame
405T
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3C
Hertz
60/50
Horsepower
100
Insulation Class
F
Inverter Speed Range
Constant 2:1
Ip Code
54
Is_Motor
Yes
Kva-Code
F
Model Number
405TTGS6548
Motor Rpm 50Hz
1500
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6313
Orientation
Horizontal
Phase
3
Rpm
1800/1500
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Thermal Protection
Thermostats (Normally Closed)
Ul
UL Listed
Voltage
230/460
Weight
1479
Marathon Motors Explosion Proof Motor, E594, 405TTGS6548, 100HP, 230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
