OEM#: Y602New OEM Original Outright

INVERTER DUTY MOTOR, 56H17E5303, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, EPNV by Marathon Motors

Your price:
$1,093.37 eachPast vendor cutoff time. Estimated to ship by 05/14 if ordered before 3:30 PM.
INVERTER DUTY MOTOR, 56H17E5303, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, EPNV by Marathon Motors
INVERTER DUTY MOTOR, 56H17E5303, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, EPNV by Marathon Motors

OEM#: Y602
INVERTER DUTY MOTOR, 56H17E5303, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, EPNV by Marathon Motors

New OEM Original Outright
Your price:
$1,093.37 each
Past vendor cutoff time. Estimated to ship by 05/14 if ordered before 3:30 PM.
Asset Information
Are you an existing customer? Sign in to access your account.
Product Overview

Marathon Motors Inverter Duty Motor, Y602, 56H17E5303, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, EPNV

For use in material handling, machine tools, crane and hoist, and other variable speed applications requiring up to 1000:1 constant torque speed range. To be in installed in hazardous environments as defined by the motor's explosion proof class and group rating.

Technical Specs
P/N: Y602 Key Specs
Item
INVERTER DUTY MOTOR, 56H17E5303, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, EPNV
OEM
Marathon Motors
OEM #
Y602
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
1.6/.8
60 Hertz Kw
0.37
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F3
Bearing-Drive-End
Ball
Catalog No.
Y602
Ce
N
Country of Origin
USA
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Frame
56C
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Horsepower
1/2
Insulation Class
F
Inverter Speed Range
Constant 1000:1
Ip Code
54
Is_Motor
Yes
Kva-Code
L
Model Number
56H17E5303
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
UL Listed
Voltage
230/460
Weight In Lbs.
31
Product Overview

Marathon Motors Inverter Duty Motor, Y602, 56H17E5303, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, EPNV

For use in material handling, machine tools, crane and hoist, and other variable speed applications requiring up to 1000:1 constant torque speed range. To be in installed in hazardous environments as defined by the motor's explosion proof class and group rating.
