OEM#: Y374New OEM Original Outright
INVERTER DUTY MOTOR, 56H17T2018, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, TENV by Marathon Motors
Your price:
$468.34 each
OEM#: Y374INVERTER DUTY MOTOR, 56H17T2018, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, TENV by Marathon Motors
New OEM Original Outright
Your price:
$468.34 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y374, 56H17T2018, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, TENV
Designed for direct replacement of PMDC or any other variable speed applications where up to a 1000:1 constant torque speed range is required. Typical uses include: machine tools, conveyors, packaging machine, and printing equipment.
Designed for direct replacement of PMDC or any other variable speed applications where up to a 1000:1 constant torque speed range is required. Typical uses include: machine tools, conveyors, packaging machine, and printing equipment.
Technical Specs
P/N: Y374 Key Specs
Item
INVERTER DUTY MOTOR, 56H17T2018, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, TENV
OEM
Marathon Motors
OEM #
Y374
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
1.8/.9
60 Hertz Fl Eff
74.00 Percent
60 Hertz Kw
0.37
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F3
Bearing-Drive-End
Ball
Catalog No.
Y374
Ce
Y
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
56C
Horsepower
1/2
Insulation Class
H
Inverter Speed Range
Constant 1000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
N
Model Number
56H17T2018
Motor Rpm 60Hz
1800
Mounting
C-Face Footless
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Ul
Recognized Construction
Voltage
230/460
Weight In Lbs.
22
Marathon Motors Inverter Duty Motor, Y374, 56H17T2018, 1/2HP, 230/460V, 1800RPM, 3PH, 56C, TENV
