OEM#: UCF209-111D1New OEM Original Outright

FLANGE BEARING 4-BOLT BALL 1-11/16 BORE by NTN

Your price:
$184.51 eachShip date will be provided after order confirmation.
HomeNTNucf209111d1
FLANGE BEARING 4-BOLT BALL 1-11/16 BORE by NTN
FLANGE BEARING 4-BOLT BALL 1-11/16 BORE by NTN

OEM#: UCF209-111D1
FLANGE BEARING 4-BOLT BALL 1-11/16 BORE by NTN

New OEM Original Outright
Your price:
$184.51 each
Ship date will be provided after order confirmation.
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: UCF209-111D1 Key Specs
Item
FLANGE BEARING 4-BOLT BALL 1-11/16 BORE
OEM
NTN
OEM #
UCF209-111D1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Housing Material Type
Cast Iron
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Shell Alvania #3 or NLGI #3 Equivalent
Bolt Hole Center-to-Center
4 9/64 in
Bolt Size
1/2 in
Bore Dia.
1 11/16 in
Dynamic Load Capacity
7,350 lb
Finish
Painted
Mounted Bearing Item
4-Bolt Flange Bearing
Overall Height
2 1/16 in
Overall Length
5 13/32 in
Overall Width
5 13/32 in
Series
Standard Duty
Shaft Locking Type
Set Screw
Static Load Capacity
4,590 lb
Temp. Range
-20 Degrees to 250 Degrees F
Technical Specs
P/N: UCF209-111D1 Key Specs
Item
FLANGE BEARING 4-BOLT BALL 1-11/16 BORE
OEM
NTN
OEM #
UCF209-111D1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Housing Material Type
Cast Iron
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Shell Alvania #3 or NLGI #3 Equivalent
Bolt Hole Center-to-Center
4 9/64 in
Bolt Size
1/2 in
Bore Dia.
1 11/16 in
Dynamic Load Capacity
7,350 lb
Finish
Painted
Mounted Bearing Item
4-Bolt Flange Bearing
Overall Height
2 1/16 in
Overall Length
5 13/32 in
Overall Width
5 13/32 in
Series
Standard Duty
Shaft Locking Type
Set Screw
Static Load Capacity
4,590 lb
Temp. Range
-20 Degrees to 250 Degrees F
Technical Specs
P/N: UCF209-111D1 Key Specs
Item
FLANGE BEARING 4-BOLT BALL 1-11/16 BORE
OEM
NTN
OEM #
UCF209-111D1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Housing Material Type
Cast Iron
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Shell Alvania #3 or NLGI #3 Equivalent
Bolt Hole Center-to-Center
4 9/64 in
Bolt Size
1/2 in
Bore Dia.
1 11/16 in
Dynamic Load Capacity
7,350 lb
Finish
Painted
Mounted Bearing Item
4-Bolt Flange Bearing
Overall Height
2 1/16 in
Overall Length
5 13/32 in
Overall Width
5 13/32 in
Series
Standard Duty
Shaft Locking Type
Set Screw
Static Load Capacity
4,590 lb
Temp. Range
-20 Degrees to 250 Degrees F
