OEM#: PCT320LFNew OEM Original Outright

J1384 GAUGE PRESSURE 4-1/2IN 30IN. HG VAC TO 0 by Winters Instruments

Your price:
$43.00 eachShip date will be provided after ordering
HomeWinters Instrumentspct320lf
J1384 GAUGE PRESSURE 4-1/2IN 30IN. HG VAC TO 0 by Winters Instruments
J1384 GAUGE PRESSURE 4-1/2IN 30IN. HG VAC TO 0 by Winters Instruments

OEM#: PCT320LF
J1384 GAUGE PRESSURE 4-1/2IN 30IN. HG VAC TO 0 by Winters Instruments

New OEM Original Outright
Your price:
$43.00 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: PCT320LF Key Specs
Item
J1384 GAUGE PRESSURE 4-1/2IN 30IN. HG VAC TO 0
OEM
Winters Instruments
OEM #
PCT320LF
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Basic Gauge Case Material
Stainless Steel
Basic Gauge Lens Material
Plastic
Basic Gauge Sensor Material
Bronze
Basic Gauge Socket Material
Brass
Basic Gauge Wetted Parts
Brass / Bronze
Calibration Certificate Included
No
Characteristics
Zero Adjustment Screw, CRN Registered
Country of Origin
China
For Use With
Most Commercial Air, Water, Steam Services
Gauge Accuracy
+/-1.00%
Gauge Application
Lead Free
Gauge Case Color
Stainless Steel
Gauge Case Material
304 Stainless Steel
Gauge Connection Location
Bottom
Gauge Connection Size
1/4 in
Gauge Connection Type
MNPT
Gauge Lens Material
Acrylic
Gauge Nominal Dial Size
4-1/2 in
Gauge Panel Mountable
No
Gauge Primary Range Units
in Hg
Gauge Primary Range Values
-30 to 0
Gauge Sensor Material
Lead Free Phosphor Bronze
Gauge Socket Material
Brass
Gauge Special Options
Zero Adjustment Screw
Liquid Filled
No
Manufacturers Warranty Length
5 yr
NSF Certified
Yes
Operating Temperature Range
-40 Degrees to 200 Degrees F
Pressure and Vacuum Gauge Type
Vacuum Gauge
Required Gauge Adapter
No
Series
PCT-LF
