OEM#: 00212ET3ECT184T-W22New OEM Original Outright

CT MOTOR 2 HP 1165 RPM 230/460 V by WEG

Your price:
$1,248.04 eachEstimated to ship by 12/30 if ordered before 4:30 PM EST
HomeWEG00212et3ect184tw22
CT MOTOR 2 HP 1165 RPM 230/460 V by WEG
CT MOTOR 2 HP 1165 RPM 230/460 V by WEG

OEM#: 00212ET3ECT184T-W22
CT MOTOR 2 HP 1165 RPM 230/460 V by WEG

New OEM Original Outright
Your price:
$1,248.04 each
Estimated to ship by 12/30 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 00212ET3ECT184T-W22 Key Specs
Item
CT MOTOR 2 HP 1165 RPM 230/460 V
OEM
WEG
OEM #
00212ET3ECT184T-W22
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature
40 Degrees C
CC Number
CC029A
Duty
Continuous
Finish
Blue
Frame
184T
Full Load Amps
6.5/3.25
HP
2
Hz
60/50
Includes
Space Heater
Ins. Class
F
Length Less Shaft
13-1/8 in
Motor Application
Cooling Tower
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.25
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1165
Nominal Efficiency
88.5 %
Overall Length
15-7/8 in
Phase
3
RPM Range
1101-1200
Shaft Diameter
1-1/8 in
Shaft Length
2-3/4 in
Standards
CE, CSA Certified (LR38324), UL Recognized (E104590)
Voltage
230/460
Voltage Compatibility
208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
Warranty
3 yr
