OEM#: U5P3DCNew OEM Original Outright

MTR 3PH 5HP 1200RPM 208-230/460 EFF 90.2 by Usem

Your price:
$1,880.00 eachShip date will be provided after ordering
HomeUsemu5p3dc
MTR 3PH 5HP 1200RPM 208-230/460 EFF 90.2 by Usem
MTR 3PH 5HP 1200RPM 208-230/460 EFF 90.2 by Usem

OEM#: U5P3DC
MTR 3PH 5HP 1200RPM 208-230/460 EFF 90.2 by Usem

New OEM Original Outright
Your price:
$1,880.00 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: U5P3DC Key Specs
Item
MTR 3PH 5HP 1200RPM 208-230/460 EFF 90.2
OEM
Usem
OEM #
U5P3DC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC030A
Country of Origin
Mexico
Duty
Continuous
Frame
215TC
Full Load Amps
15-14/7
Green Certification or Other Recognition
NEMA Premium(R) Rated
HP
5 hp
Hz
60/50
Ins. Class
F
Length Less Shaft
16-3/4 in
Manufacturers Warranty Length
2 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Aluminum
Motor Mounting Position
Horizontal or Vertical Shaft Down
Motor Mounting Type
Face/Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1200
Nominal Efficiency
90.2 %
Number of Speeds
1
Overall Length
20-1/4 in
Phase
3
RPM Group
1101-1200
RPM Range
1101-1200
Shaft Diameter
1-3/8 in
Shaft Length
3-3/8 in
Standards
CE, CSA, UL
Voltage
208-230/460
