OEM#: U2P2DCRNew OEM Original Outright
GENERAL PURPOSE MOTOR TEFC 2 HP 1750 RPM by Usem
Your price:
$716.07 eachShip date will be provided after ordering
OEM#: U2P2DCRGENERAL PURPOSE MOTOR TEFC 2 HP 1750 RPM by Usem
New OEM Original Outright
Your price:
$716.07 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: U2P2DCR Key Specs
Item
GENERAL PURPOSE MOTOR TEFC 2 HP 1750 RPM
OEM
Usem
OEM #
U2P2DCR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC030A
Country of Origin
Mexico
Duty
Continuous
Frame
145TC
Full Load Amps
5.9/2.8
HP
2
Hz
60
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
11 in
Manufacturers Warranty Length
1 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Face
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1750
Nominal Efficiency
86.5 %
Number of Speeds
1
Overall Length
13-1/8 in
Phase
3
Shaft Diameter
7/8 in
Shaft Length
2-1/8 in
Standards
CSA (258501), UL (E47479)
Voltage
208-230/460
