OEM#: SMART5000XFMRXLNew OEM Original Outright
UPS 5000VA 3750W SMART RACKMOUNT AVR 120V/208V 5KVA USB DB9 3URM by Tripp Lite
Your price:
$4,127.15 each $6,136.42 Savings: $2,009.27 (33%)
Estimated to ship by 11/28 if ordered before 12:30 PM EST
View All
OEM#: SMART5000XFMRXLUPS 5000VA 3750W SMART RACKMOUNT AVR 120V/208V 5KVA USB DB9 3URM by Tripp Lite
New OEM Original Outright
Your price:
$4,127.15 each
$6,136.42 Savings: $2,009.27 (33%)
SmartPro 208 & 120V 5kVA 3.75kW Line-Interactive Sine Wave UPS, 3U, Extended Run, Network Card Options, USB, DB9
Estimated to ship by 11/28 if ordered before 12:30 PM EST
Asset Information
2-Year Warranty, 3 Year With Registration
ADD TO LIST
Product Overview
Tripp Lite 5kVA Smart RM UPS. 5000VA line-interactive UPS for server, network and telecommunications equipment. UPS with internal batteries requires 3 rack spaces installed. Accepts 208V nominal input voltage. Simultaneous 208 & 120V output. Corrects brownouts and overvoltages from 167V to 260V. Sine wave output. Maintains battery-derived AC output during blackouts and severe voltage fluctuations. Expandable runtime with optional external battery packs. 11 output receptacles. NEMA L6-30P input connection with support for user-supplied 50A or hardwire input. Network-grade AC surge and noise suppression. Network management interfaces include USB, DB9 serial and slot for Network Management Card options. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all network interfaces simultaneously. PowerAlert UPS monitoring software is available via free download. Emergency Power Off (EPO) interface. Integrated 8-bank switched PDU. 3-stage metered current monitoring and battery charge LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rack mounting accessories included; 2-9USTAND and 2POSTRMKITHD accessories available. Field-replaceable, hot-swappable internal batteries and battery packs.
- Package Includes:
• SMART 5000XFMRXL UPS System
• USB & DB9 Serial Cabling
• Mounting hardware for 4-post rackmount installation
• Instruction manual
Features
- 208 & 120V output during brownouts to 167 and overvoltages to 260V
- 3U all-in-one chassis; 8 single-outlet switched load banks; 97% efficiency
- 5kVA / 5000VA line interactive 3U rack/tower UPS; Sine wave output
- NEMA L6-30P input; 8 NEMA 5-15/20R, 2 L6-20R & 1 L6-30R outlets
- USB, Serial, EPO & Network Management Card options
Technical Specs
P/N: SMART5000XFMRXL Key Specs
Item
UPS 5000VA 3750W SMART RACKMOUNT AVR 120V/208V 5KVA USB DB9 3URM
OEM
Tripp Lite
OEM #
SMART5000XFMRXL
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Input Connectors
1 x power NEMA L6-30
Input Voltage
AC 208 V
Output Voltage
AC 120/208 V
Output connectors
8 x power NEMA 5-20 - 2 x power NEMA L6-20 - 1 x power NEMA L6-30
Power Capacity
3.75 kW / 5000 VA
Rack Size
3U
Run Time (Up To)
8.5 min at full load
Equivalents
Tripp Lite 5kVA Smart RM UPS. 5000VA line-interactive UPS for server, network and telecommunications equipment. UPS with internal batteries requires 3 rack spaces installed. Accepts 208V nominal input voltage. Simultaneous 208 & 120V output. Corrects brownouts and overvoltages from 167V to 260V. Sine wave output. Maintains battery-derived AC output during blackouts and severe voltage fluctuations. Expandable runtime with optional external battery packs. 11 output receptacles. NEMA L6-30P input connection with support for user-supplied 50A or hardwire input. Network-grade AC surge and noise suppression. Network management interfaces include USB, DB9 serial and slot for Network Management Card options. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all network interfaces simultaneously. PowerAlert UPS monitoring software is available via free download. Emergency Power Off (EPO) interface. Integrated 8-bank switched PDU. 3-stage metered current monitoring and battery charge LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rack mounting accessories included; 2-9USTAND and 2POSTRMKITHD accessories available. Field-replaceable, hot-swappable internal batteries and battery packs.
- Package Includes:
• SMART 5000XFMRXL UPS System
• USB & DB9 Serial Cabling
• Mounting hardware for 4-post rackmount installation
• Instruction manual
