OEM#: PDUMH32HVATNETNew OEM Original Outright
POWER STRIP 18 OUTLET by Tripp Lite
Your price:
$1,761.41 each $2,013.00 Savings: $251.59 (12%)
View All
OEM#: PDUMH32HVATNETPOWER STRIP 18 OUTLET by Tripp Lite
New OEM Original Outright
Your price:
$1,761.41 each
$2,013.00 Savings: $251.59 (12%)
TAA-Compliant 7.4kW Single-Phase ATS / Switched PDU, LX Platform Network Interface, 230V Outlets (16 C13 & 2 C19), 2 IEC309 32A Blue Inputs, 2U Rack-Mount, TAA
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The PDUMH32HVATNET 7.4kW Single-Phase 230V ATS/Switched PDU provides remote power monitoring and enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms, it mounts in 2U of space in EIA-standard racks and features 18 switched outlets (16 C13 and two C19) in two load banks, each bank protected by a 20A circuit breaker.Dual 3-meter input cords with IEC309 32A Blue (2P+E) plugs connect to separate primary and secondary single-phase 230V power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 1–5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.Built-in LX Platform network management interface card. The Java-free LX Platform HTML5-based network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.
- Package Includes:
• PDUMH32HVATNET 7.4kW Single-Phase 230V ATS / Switched PDU
• Rack-mounting brackets
• Plug-lock cable retention sleeves
• USB configuration cable
• Owner’s manual
Features
- 16 C13 and 2 C19 230V switched outlets in2 breakeredload banks
- Automatic transfer switching within 1-5 ms
- Digital LED display for real-time status and currentmonitoring
- Ethernet network interface for remote access
- Single-phase IEC309 230V 32A Blue (2P+E) input
Technical Specs
P/N: PDUMH32HVATNET Key Specs
Item
POWER STRIP 18 OUTLET
OEM
Tripp Lite
OEM #
PDUMH32HVATNET
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
AC Input
IEC 309 (2)
AC Outlets
18
AC Output
IEC 320-C13 (16); C19 (2)
Amperage Rating
32 A
Cord Length
10 ft
Dimensions (WxDxH)
17.5 in x 12.5 in x 3.5 in
Housing Material
Metal
Input Connectors
2 x power IEC 60309 32A
Input Voltage
AC 200/208/220/230/240 V
Input Wiring
1-phase
Mounting Type
Rack; Horizontal
Networking
Ethernet
Output Voltage
AC 200/208/220/230/240 V
Output connectors
16 x power IEC 60320 C13 - 2 x power IEC 60320 C19
Overload Protection
Circuit Breaker
Power Capacity
7.7 kW
Rack Size
19" - 2U
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH
TAA Compliant
TAA Compliant
Voltage Rating
230 V
Weight
13.67 lbs
The PDUMH32HVATNET 7.4kW Single-Phase 230V ATS/Switched PDU provides remote power monitoring and enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms, it mounts in 2U of space in EIA-standard racks and features 18 switched outlets (16 C13 and two C19) in two load banks, each bank protected by a 20A circuit breaker.Dual 3-meter input cords with IEC309 32A Blue (2P+E) plugs connect to separate primary and secondary single-phase 230V power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 1–5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.Built-in LX Platform network management interface card. The Java-free LX Platform HTML5-based network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.
