OEM#: SVX30KM1P4BNew OEM Original Outright
30KVA SMART ONLINE 3-PHASE UPS 400/230V MEDIUM FRAME 4 BATTERIES by Tripp Lite
Your price:
$47,073.10 each $53,832.00 Savings: $6,758.90 (13%)
View All
OEM#: SVX30KM1P4B30KVA SMART ONLINE 3-PHASE UPS 400/230V MEDIUM FRAME 4 BATTERIES by Tripp Lite
New OEM Original Outright
Your price:
$47,073.10 each
$53,832.00 Savings: $6,758.90 (13%)
SmartOnline SVX Series 30kVA 400/230V 50/60Hz Modular Scalable 3-Phase On-Line Double-Conversion Medium-Frame UPS System, 4 Battery Modules
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Tripp Lite's SVX30KM1P4B 30kVA/30kW SmartOnline® Medium-Frame UPS includes installed input, bypass and output breakers, a static transfer switch (STS) and 1 included 30kVA SVX30PM power module. This system supports the addition of up to 3 additional user-installable SVX30PM power modules to accommodate increased capacity up to 90kW with N+1 fault-tolerance. Four internal battery modules are included with space for up to 1 additional SVXBM internal battery module or any number of compatible ±240VDC external battery packs (sold separately). Featuring a modular, scalable design with high-efficiency voltage and frequency independent/VFI operation, Tripp Lite's SVX Series SmartOnline UPS systems are ideal for the protection of a wide variety of critical IT systems. Scalable, modular configuration enables UPS capacity upgrades and hot-swap power supply maintenance without costly downtime. Over 95% efficient in standard online mode and over 99% efficient in optional economy mode enables reduced operating and cooling costs. Unity power factor configuration provides equal kVA and kW output ratings for up to 25% more wattage capacity than common 0.8 – 0.9 power factor competing designs. Network-grade sine-wave AC output with 1% output voltage regulation and less than 1.5% output total harmonic distortion. Advanced IGBT inverter with Digital Signal Processor (DSP) technology provides for less than 3% input total harmonic distortion (THDi) to support 1:1 generator sizing. Dual-input hardwire design enables operation from one or two input power sources for enhanced system availability. N+1 fault-tolerance is configurable anytime there is an "extra" SVX30PM 30kW power module installed beyond the minimum required quantity. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure.
- Package Includes:
• SVX30KM1P4B Medium-Frame Modular UPS System
• (1) SVX30PM 30kVA power module
• (4) SVXBM battery modules
• Pre-installed WEBCARDLX network interface
• Owner’s manual
Features
- 30kVA/30kW Modular, Scalable, 3-Phase Medium-Frame Tower UPS
- High efficiency on-line UPS with DSP/IGBT technology and 1% output voltage regulation
- Includes 4 internal battery modules, Additional battery options available, Tested to CE for worldwide applications
- Pre-installed WEBCARDLX network interface, Economy mode option reduces operating and cooling costs
- Supports 3-Phase 220/380V, 230/400V or 240/415V AC, 50/60Hz, Wye, Scalable to 90kVA with N+1 redundancy
Technical Specs
P/N: SVX30KM1P4B Key Specs
Item
30KVA SMART ONLINE 3-PHASE UPS 400/230V MEDIUM FRAME 4 BATTERIES
OEM
Tripp Lite
OEM #
SVX30KM1P4B
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Batteries Qty
4 (installed) / 5 (supported)
Battery
Expandable
Dimensions (WxDxH)
23.6 in x 43.3 in x 79.1 in
Input Connectors
Hardwire
Input Voltage
AC 220/230/240/380/400/415 V
Input Wiring
3-phase WYE (star)
Networking
RS-232
Output Voltage
AC 220/230/240/380/400/415 V
Output connectors
Hardwire
Power Capacity
30 kW / 30000 VA
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH
Run Time (Up To)
13 min
Weight
1596.99 lbs
Tripp Lite's SVX30KM1P4B 30kVA/30kW SmartOnline® Medium-Frame UPS includes installed input, bypass and output breakers, a static transfer switch (STS) and 1 included 30kVA SVX30PM power module. This system supports the addition of up to 3 additional user-installable SVX30PM power modules to accommodate increased capacity up to 90kW with N+1 fault-tolerance. Four internal battery modules are included with space for up to 1 additional SVXBM internal battery module or any number of compatible ±240VDC external battery packs (sold separately). Featuring a modular, scalable design with high-efficiency voltage and frequency independent/VFI operation, Tripp Lite's SVX Series SmartOnline UPS systems are ideal for the protection of a wide variety of critical IT systems. Scalable, modular configuration enables UPS capacity upgrades and hot-swap power supply maintenance without costly downtime. Over 95% efficient in standard online mode and over 99% efficient in optional economy mode enables reduced operating and cooling costs. Unity power factor configuration provides equal kVA and kW output ratings for up to 25% more wattage capacity than common 0.8 – 0.9 power factor competing designs. Network-grade sine-wave AC output with 1% output voltage regulation and less than 1.5% output total harmonic distortion. Advanced IGBT inverter with Digital Signal Processor (DSP) technology provides for less than 3% input total harmonic distortion (THDi) to support 1:1 generator sizing. Dual-input hardwire design enables operation from one or two input power sources for enhanced system availability. N+1 fault-tolerance is configurable anytime there is an "extra" SVX30PM 30kW power module installed beyond the minimum required quantity. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure.
