OEM#: SV60KS3P3BNew OEM Original Outright
60KVA SMART ONLINE 3-PHASE UPS SMALL FRAME MODULAR 3 BATTERIES by Tripp Lite
0
View All
OEM#: SV60KS3P3B60KVA SMART ONLINE 3-PHASE UPS SMALL FRAME MODULAR 3 BATTERIES by Tripp Lite
New OEM Original Outright
SmartOnline SV Series 60kVA Small-Frame Modular Scalable 3-Phase On-Line Double-Conversion 208/120V 50/60 Hz UPS System, 3 Battery Modules
Asset Information
2-Year Limited Warranty
ADD TO LIST
Product Overview
The SV60KS3P3B SmartOnline® SV Series 60kVA Small-Frame 3-Phase On-Line Double-Conversion UPS System delivers true scalability and offers the highest level of secure, uninterrupted power protection. Featuring a modular, scalable design with high-efficiency voltage and frequency independent (VFI) operation, this on-line UPS system with a high 0.9 power factor is ideal for protecting a variety of critical IT systems.The SV60KS3P3B includes pre-installed input, bypass and output breakers, as well as a static transfer switch (STS), three 20kVA SV20PM power modules and three SVBM battery modules. It comes fully configured for 60kVA total capacity or 40kVA with enhanced N+1 protection. External ±120VDC battery options, such as BP240V370, are also available from Tripp Lite for even more extended runtime.The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network.With up to 92% efficiency in standard mode and up to 98% efficiency in optional economy mode, this 60kVA UPS system helps you reduce operating and cooling costs. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure. Front-panel display offers full UPS condition and status reporting.
- Package Includes:
• SV60KS3P3B SmartOnline SV Series 60kVA Small-Frame 3-Phase On-Line Double-Conversion UPS System
• Pre-installed WEBCARDLX network interface
• (3) SV20PM 20kVA power modules
• (3) SVBM battery modules
• Owner’s manual
Features
- DSP/IGBT technology and 1% output voltage regulation
- Economy mode option helps reduce operating and cooling costs
- Fully configured for 60kVA capacity or 40kVA with N+1 fault tolerance
- Includes 3 internal battery modules, external battery options available
- Pre-installed WEBCARDLX network interface for 24/7 remote access
Technical Specs
P/N: SV60KS3P3B Key Specs
Item
60KVA SMART ONLINE 3-PHASE UPS SMALL FRAME MODULAR 3 BATTERIES
OEM
Tripp Lite
OEM #
SV60KS3P3B
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Batteries Qty
3
Battery
Expandable
Dimensions (WxDxH)
23.6 in x 43.3 in x 58.1 in
Input Connectors
Hardwire
Input Voltage
AC 120/127/208/220 V
Input Wiring
3-phase WYE (star)
Networking
RS-232
Output Voltage
AC 120/127/208/220 V
Output connectors
Hardwire
Power Capacity
54 kW / 60000 VA
Remote Management Protocol
SNMP, Telnet, SSH
Run Time (Up To)
3.9 min
Weight
1512.99 lbs
The SV60KS3P3B SmartOnline® SV Series 60kVA Small-Frame 3-Phase On-Line Double-Conversion UPS System delivers true scalability and offers the highest level of secure, uninterrupted power protection. Featuring a modular, scalable design with high-efficiency voltage and frequency independent (VFI) operation, this on-line UPS system with a high 0.9 power factor is ideal for protecting a variety of critical IT systems.The SV60KS3P3B includes pre-installed input, bypass and output breakers, as well as a static transfer switch (STS), three 20kVA SV20PM power modules and three SVBM battery modules. It comes fully configured for 60kVA total capacity or 40kVA with enhanced N+1 protection. External ±120VDC battery options, such as BP240V370, are also available from Tripp Lite for even more extended runtime.The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network.With up to 92% efficiency in standard mode and up to 98% efficiency in optional economy mode, this 60kVA UPS system helps you reduce operating and cooling costs. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure. Front-panel display offers full UPS condition and status reporting.
- Package Includes:
• SV60KS3P3B SmartOnline SV Series 60kVA Small-Frame 3-Phase On-Line Double-Conversion UPS System
• Pre-installed WEBCARDLX network interface
• (3) SV20PM 20kVA power modules
• (3) SVBM battery modules
• Owner’s manual
