UPS 1000VA 500W INTERNATIONAL SMART TOWER LCD AVR 230V RJ11 C13

HomeTripp LiteSMX1000LCD
UPS 1000VA 500W INTERNATIONAL SMART TOWER LCD AVR 230V RJ11 C13
UPS 1000VA 500W INTERNATIONAL SMART TOWER LCD AVR 230V RJ11 C13
UPS 1000VA 500W INTERNATIONAL SMART TOWER LCD AVR 230V RJ11 C13

UPS 1000VA 500W INTERNATIONAL SMART TOWER LCD AVR 230V RJ11 C13

Product Overview
The SMX1000LCD SmartPro 230V 1kVA 500W Line-Interactive UPS provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up home/office workstations, media centers and home entertainment systems, the SMX1000LCD switches to battery mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss.Featuring six C13 outlets and a C14 inlet that accepts a user-supplied AC power cord, the SMX1000LCD has an internal battery that provides 11 minutes of support at half load and three minutes at full load. It can also power an entry-level PC up to 60 minutes or a single DVR/VCR component up to three hours. Three of the six outlets provide surge protection only for printers and other non-essential devices. A front-panel LCD screen lets you configure settings and monitor operating data, such as voltage, battery and load statuses. Automatic voltage regulation (AVR) maintains 230V nominal output over an input range of 171V to 266V without using battery power. EMI/RFI noise filtering improves your equipment’s performance and prevents damage. A 480-joule surge suppression rating protects your equipment from harmful power surges. With Tripp Lite’s free downloadable PowerAlert software, SMX1000LCD enables safe unattended system shutdown and file saves in case of a prolonged power failure.

    Package Includes:
    • SMX1000LCD SmartPro 230V 1kVA 500W Line-Interactive UPS
    • USB cable
    • RJ11 cable
    • (2) IEC-320 C13-to-C14 power cables
    • Owner’s manual
Technical Specs
P/N: SMX1000LCD Key Specs
Item
UPS 1000VA 500W INTERNATIONAL SMART TOWER LCD AVR 230V RJ11 C13
OEM
Tripp Lite
OEM #
SMX1000LCD
Returnable
No
Warranty
Backup Time (Half/Full Load)
11 min/3 min
Battery Form Factor
Internal
Color
Attractive black
Dimensions (WxDxH)
3.5 in x 6.5 in x 12 in
Input Connectors
1 x power IEC 60320 C14
Input Voltage
AC 230 V
Input Voltage - UPS Systems
230V AC
Medical Grade
No
Networking
USB
Number of Outlets
6
Outlet Type - UPS Systems
UPS/Surge
Output Voltage
AC 230 V ± 5%
Output Voltage - UPS Systems
220V AC, 230V AC, 240V AC
Output connectors
3 x power IEC 60320 C13 (surge) - 3 x power IEC 60320 C13 (UPS and surge)
Power Capacity
500 Watt / 1000 VA
Product Type
UPS System
Rack Size
2U
Run Time (Up To)
3 min at full load
UPS Type
Line Interactive
VA Rating - UPS Systems
1 kVA
Watts - UPS Systems
500 W
Weight
14.55 lbs
The SMX1000LCD SmartPro 230V 1kVA 500W Line-Interactive UPS provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up home/office workstations, media centers and home entertainment systems, the SMX1000LCD switches to battery mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss.Featuring six C13 outlets and a C14 inlet that accepts a user-supplied AC power cord, the SMX1000LCD has an internal battery that provides 11 minutes of support at half load and three minutes at full load. It can also power an entry-level PC up to 60 minutes or a single DVR/VCR component up to three hours. Three of the six outlets provide surge protection only for printers and other non-essential devices. A front-panel LCD screen lets you configure settings and monitor operating data, such as voltage, battery and load statuses. Automatic voltage regulation (AVR) maintains 230V nominal output over an input range of 171V to 266V without using battery power. EMI/RFI noise filtering improves your equipment’s performance and prevents damage. A 480-joule surge suppression rating protects your equipment from harmful power surges. With Tripp Lite’s free downloadable PowerAlert software, SMX1000LCD enables safe unattended system shutdown and file saves in case of a prolonged power failure.

    Package Includes:
    • SMX1000LCD SmartPro 230V 1kVA 500W Line-Interactive UPS
    • USB cable
    • RJ11 cable
    • (2) IEC-320 C13-to-C14 power cables
    • Owner’s manual
