OEM#: SMART1200XLHGNew OEM Original Outright
SMART1200XLHG by Tripp Lite
Your price:
$1,066.76 each $1,711.00 Savings: $644.24 (38%)
OEM#: SMART1200XLHGSMART1200XLHG by Tripp Lite
New OEM Original Outright
Your price:
$1,066.76 each
$1,711.00 Savings: $644.24 (38%)
SmartPro 120V 1kVA 750W Medical-Grade Line-Interactive Tower UPS, 4 Outlets, Full Isolation, Expandable Runtime
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Tripp Lite’s SMART1200XLHG medical-grade UPS system provides dependable battery backup and is fully compliant with UL 60601-1 regulations when plugged into a hospital-grade outlet, making it ideal for use in patient-care vicinities. The 1kVA/750W capacity provides up to 28 minutes of runtime for a half load or 10 minutes for a full load, so you can work through short power failures and perform an orderly system shutdown in a prolonged blackout.Built-in line-interactive voltage regulation corrects brownouts as low as 81V and overvoltages as high as 143V to normal 120V nominal output without drawing battery power. The SMART1200XLHG’s built-in isolation transformer with Faraday shield offers full isolation and removes common mode noise, while maintaining full AC surge suppression in all modes.This UPS system features four NEMA 5-15R-HG hospital-grade outlets and has a hospital-grade NEMA 5-15P-HG plug with a six-foot cord for flexibility in placement. All four outlets provide both backup protection and surge protection rated to 940 joules.The SMART1200XLHG also features diagnostic LEDs, as well as a USB port and a DB9 serial port that work with Tripp Lite’s included PowerAlert software for safe, unattended system shutdown and file saves in the event of a prolonged power failure.Application Usage This UPS contains a lead acid battery designed to be connected continuously to an AC power source, except during brief power outages. It is not intended for frequent charge/discharge cycles, such as mobile cart applications where the UPS is often disconnected from the power source. Using theSMART1200XLHGin this type of application will void the battery warranty. For mobile applications, Tripp Lite recommends theSMART1200XLHGLwith lithium iron phosphate (LiFePo4) battery
- Package Includes:
• SMART1200XLHG 1kVA/750W Medical-Grade Tower UPS System
• USB monitoring cable, 6 ft.
• DB9 serial monitoring cable, 6 ft.
• PowerAlert Software
• Owner’s Manual
Features
- 28 min. runtime at half load, 10 min. at full load
- 4 NEMA 5-15R-HG outlets and 120V NEMA 5-15P-HG plug
- 940-joule surge protection rating protects connected equipment
- Alarm mute/quiet control ideal for use near patients
- Floating AC output prevents noise coupling
Technical Specs
P/N: SMART1200XLHG Key Specs
Item
SMART1200XLHG
OEM
Tripp Lite
OEM #
SMART1200XLHG
Condition
New OEM Original
Returnable
No
Warranty
24 Month
Automatic Volts Regulation
Yes
Backup Time (Half/Full Load)
27.5 min/11 min
Cord Length
6 ft
Depth
9 in
Display Type
LED
Fax/Modem Line Protection
No
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Height
12.7 in
Hz
60
Includes
PowerAlert Software and Cables
Input Current
9.2 A
Input Voltage - UPS Systems
120V AC
Medical Grade
Yes
Mounting - UPS Systems
Tower/Wall
NEMA Plug Configuration
5-15P
NEMA Receptacle Configuration
5-15R
Number of Outlets
4
Outlet Type - UPS Systems
UPS/Surge
Output Voltage - UPS Systems
115V AC, 120V AC
Phase
1
Ports
DB9 Serial, USB
Special Features
Advanced AVR Corrects Brownouts and Overvoltages, Pure Sine Wave Output, Extended Runtime w/BP36V15-2U, BP36V42-3U
Standards
CSA, FCC Part 15 Category A (EMI), UL1778, UL60601-1 (Medical Grade)
Transfer Time
2 to 4 msec
UPS Type
Line Interactive
VA Rating - UPS Systems
1 kVA
Watts - UPS Systems
750 W
Width
7.5 in
Tripp Lite’s SMART1200XLHG medical-grade UPS system provides dependable battery backup and is fully compliant with UL 60601-1 regulations when plugged into a hospital-grade outlet, making it ideal for use in patient-care vicinities. The 1kVA/750W capacity provides up to 28 minutes of runtime for a half load or 10 minutes for a full load, so you can work through short power failures and perform an orderly system shutdown in a prolonged blackout.Built-in line-interactive voltage regulation corrects brownouts as low as 81V and overvoltages as high as 143V to normal 120V nominal output without drawing battery power. The SMART1200XLHG’s built-in isolation transformer with Faraday shield offers full isolation and removes common mode noise, while maintaining full AC surge suppression in all modes.This UPS system features four NEMA 5-15R-HG hospital-grade outlets and has a hospital-grade NEMA 5-15P-HG plug with a six-foot cord for flexibility in placement. All four outlets provide both backup protection and surge protection rated to 940 joules.The SMART1200XLHG also features diagnostic LEDs, as well as a USB port and a DB9 serial port that work with Tripp Lite’s included PowerAlert software for safe, unattended system shutdown and file saves in the event of a prolonged power failure.Application Usage This UPS contains a lead acid battery designed to be connected continuously to an AC power source, except during brief power outages. It is not intended for frequent charge/discharge cycles, such as mobile cart applications where the UPS is often disconnected from the power source. Using theSMART1200XLHGin this type of application will void the battery warranty. For mobile applications, Tripp Lite recommends theSMART1200XLHGLwith lithium iron phosphate (LiFePo4) battery
- Package Includes:
• SMART1200XLHG 1kVA/750W Medical-Grade Tower UPS System
• USB monitoring cable, 6 ft.
• DB9 serial monitoring cable, 6 ft.
• PowerAlert Software
• Owner’s Manual
Product Overview
Tripp Lite’s SMART1200XLHG medical-grade UPS system provides dependable battery backup and is fully compliant with UL 60601-1 regulations when plugged into a hospital-grade outlet, making it ideal for use in patient-care vicinities. The 1kVA/750W capacity provides up to 28 minutes of runtime for a half load or 10 minutes for a full load, so you can work through short power failures and perform an orderly system shutdown in a prolonged blackout.Built-in line-interactive voltage regulation corrects brownouts as low as 81V and overvoltages as high as 143V to normal 120V nominal output without drawing battery power. The SMART1200XLHG’s built-in isolation transformer with Faraday shield offers full isolation and removes common mode noise, while maintaining full AC surge suppression in all modes.This UPS system features four NEMA 5-15R-HG hospital-grade outlets and has a hospital-grade NEMA 5-15P-HG plug with a six-foot cord for flexibility in placement. All four outlets provide both backup protection and surge protection rated to 940 joules.The SMART1200XLHG also features diagnostic LEDs, as well as a USB port and a DB9 serial port that work with Tripp Lite’s included PowerAlert software for safe, unattended system shutdown and file saves in the event of a prolonged power failure.Application Usage This UPS contains a lead acid battery designed to be connected continuously to an AC power source, except during brief power outages. It is not intended for frequent charge/discharge cycles, such as mobile cart applications where the UPS is often disconnected from the power source. Using theSMART1200XLHGin this type of application will void the battery warranty. For mobile applications, Tripp Lite recommends theSMART1200XLHGLwith lithium iron phosphate (LiFePo4) battery
- Package Includes:
• SMART1200XLHG 1kVA/750W Medical-Grade Tower UPS System
• USB monitoring cable, 6 ft.
• DB9 serial monitoring cable, 6 ft.
• PowerAlert Software
• Owner’s Manual
Features
- 28 min. runtime at half load, 10 min. at full load
- 4 NEMA 5-15R-HG outlets and 120V NEMA 5-15P-HG plug
- 940-joule surge protection rating protects connected equipment
- Alarm mute/quiet control ideal for use near patients
- Floating AC output prevents noise coupling
