OEM#: PDUMH32HVATNew OEM Original Outright

PDU METERED 7.4KW 230V ATS 16 C13 2 C19 2 IEC309 CORDS 32A 2URM by Tripp Lite

Your price:
$1,531.33 each
$1,750.00 Savings: $218.67 (12%)
Ready to ship
HomeTripp LitePDUMH32HVAT
PDU METERED 7.4KW 230V ATS 16 C13 2 C19 2 IEC309 CORDS 32A 2URM by Tripp Lite
PDU METERED 7.4KW 230V ATS 16 C13 2 C19 2 IEC309 CORDS 32A 2URM by Tripp Lite
PDU METERED 7.4KW 230V ATS 16 C13 2 C19 2 IEC309 CORDS 32A 2URM by Tripp Lite
PDU METERED 7.4KW 230V ATS 16 C13 2 C19 2 IEC309 CORDS 32A 2URM by Tripp Lite
View All

OEM#: PDUMH32HVAT
PDU METERED 7.4KW 230V ATS 16 C13 2 C19 2 IEC309 CORDS 32A 2URM by Tripp Lite

New OEM Original Outright
Your price:
$1,531.33 each
$1,750.00 Savings: $218.67 (12%)

TAA-Compliant 7.4kW Single-Phase ATS/Metered PDU, 230V Outlets (16 C13 & 2 C19), 2 IEC 309 32A Blue Cords, 2U Rack-Mount

Ready to ship
Asset Information

1-Year Limited Warranty

Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The PDUMH32HVAT 7.4kW Single-Phase 230V ATS/Metered PDU provides power monitoring and enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms, it mounts in 2U of space in EIA-standard 19-inch racks and features 18 outlets (16 C13 and two C19) in two load banks, each bank protected by a 20A circuit breaker.Dual three-meter input cords with IEC 309 32A Blue (2P+E) plugs connect to separate primary and secondary single-phase 230V power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 1–5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption. Multifunction digital display with LED indicators reports output current, voltage and kW loading information.

    Package Includes:
    • PDUMH32HVAT 7.4kW Single-Phase 230V ATS/Metered PDU
    • Rack-mounting brackets
    • Cord retention brackets
    • Cable ties
    • Owner’s manual
Features
  • 16 C13 and 2 C19 outlets in 2 load banks
  • Automatic transfer switching within 1-5 ms
  • Mounts in 2U of space in EIA-standard 19 in. racks
  • Multifunction digital display with LED indicators
  • Single-phase IEC 309 32A Blue (2P+E) input and 230V output
Technical Specs
P/N: PDUMH32HVAT Key Specs
Item
PDU METERED 7.4KW 230V ATS 16 C13 2 C19 2 IEC309 CORDS 32A 2URM
OEM
Tripp Lite
OEM #
PDUMH32HVAT
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Dimensions (WxDxH)
17.5 in x 12.5 in x 3.5 in
Input Connectors
2 x power IEC 60309 32A
Input Voltage
AC 200/208/220/230/240 V
Input Wiring
1-phase
Output Voltage
AC 200/208/220/230/240 V
Output connectors
16 x power IEC 60320 C13 - 230 V - 2 x power IEC 60320 C19 - 230 V
Power Capacity
7.4 kW
Rack Size
19" - 2U
TAA Compliant
TAA Compliant
Weight
13.69 lbs
