OEM#: PDU3EVSR6L1530New OEM Original Outright
10KW 3-PHASE SWITCHED PDU LX INTERFACE 200/208/240V 30 OUTLETS by Tripp Lite
Your price:
$2,203.07 each $2,462.00 Savings: $258.93 (11%)
View All
OEM#: PDU3EVSR6L153010KW 3-PHASE SWITCHED PDU LX INTERFACE 200/208/240V 30 OUTLETS by Tripp Lite
New OEM Original Outright
Your price:
$2,203.07 each
$2,462.00 Savings: $258.93 (11%)
10kW 3-Phase Switched PDU, LX Interface, 208/240V Outlets (24 C13/6 C19), LCD, NEMA L15-30P, 1.8m/6 ft. Cord, 0U 1.8m/70 in. Height, TAA
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The PDU3EVSR6L1530 10kW 3-Phase Switched Power Distribution Unit provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet. Recommended for any IT or industrial application, it features 30 switched outlets (24 C13 and 6 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A six-foot cord with NEMA L15-30P plug connects the PDU to a compatible AC power source, generator or protected UPS.The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.A color touchscreen LCD lets you toggle between menus to monitor input current level per phase, output current per load bank and per outlet with ±1% billing-grade accuracy, environmental sensor data and network information. It also generates a unique QR code to allow access to the switchable PDU through a mobile device.The 0U PDU mounts vertically in racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
- Package Includes:
• PDU3EVSR6L1530 10kW 3-Phase Switched PDU
• Built-in LX Platform interface
• Configuration cable
• (30) Plug-lock insert sleeves
• Rack-mounting hardware
• PDUMVROTATEBRKT mounting bracket accessory
• Owner’s manual
Features
- 10kW 208/240V switched 0U PDU
- 30 individually controllable outlets-24 C13, 6 C19
- Built-in LX Platform interface for remote access
- NEMA L15-30P input with 6 ft. AC power cord
- Touchscreen LCD with mobile access option via QR code
Technical Specs
P/N: PDU3EVSR6L1530 Key Specs
Item
10KW 3-PHASE SWITCHED PDU LX INTERFACE 200/208/240V 30 OUTLETS
OEM
Tripp Lite
OEM #
PDU3EVSR6L1530
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Cord Length
6 ft
Dimensions (WxDxH)
2.2 in x 2.9 in x 70 in
Input Connectors
1 x power NEMA L15-30
Input Voltage
AC 200/208/240 V
Input Wiring
3-phase
Networking
Ethernet 10/100, USB, serial
Output Voltage
AC 200/208/240 V
Output connectors
24 x power IEC 60320 C13 - 6 x power IEC 60320 C19
Power Capacity
10 kW
Rack Size
0U
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, SMTP
TAA Compliant
TAA Compliant
Weight
20 lbs
The PDU3EVSR6L1530 10kW 3-Phase Switched Power Distribution Unit provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet. Recommended for any IT or industrial application, it features 30 switched outlets (24 C13 and 6 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A six-foot cord with NEMA L15-30P plug connects the PDU to a compatible AC power source, generator or protected UPS.The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.A color touchscreen LCD lets you toggle between menus to monitor input current level per phase, output current per load bank and per outlet with ±1% billing-grade accuracy, environmental sensor data and network information. It also generates a unique QR code to allow access to the switchable PDU through a mobile device.The 0U PDU mounts vertically in racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
- Package Includes:
• PDU3EVSR6L1530 10kW 3-Phase Switched PDU
• Built-in LX Platform interface
• Configuration cable
• (30) Plug-lock insert sleeves
• Rack-mounting hardware
• PDUMVROTATEBRKT mounting bracket accessory
• Owner’s manual
