OEM#: 1WD80New OEM Original Outright

ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE by Speedaire

Your price:
$4,707.72 eachEstimated to ship by 12/06 if ordered before 4:30 PM EST
HomeSpeedaire1wd80
ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE by Speedaire
ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE by Speedaire

OEM#: 1WD80
ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE by Speedaire

New OEM Original Outright
Your price:
$4,707.72 each
Estimated to ship by 12/06 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 1WD80 Key Specs
Item
ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE
OEM
Speedaire
OEM #
1WD80
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
(F)NPT Outlet
1/2 in
ASME Tank
Yes
Amps
14/13.8/6.9
Compressor Package Type
Base Model
Control
Dual Control
Cylinder Material
Aluminum with Cast Iron Liner
Enclosure
NEMA 1
Finish
Enamel
Free Air CFM @ Max. Pressure - Air Compressor
17.3
HP - Air Compressor
5.0 hp
Hz
60
Includes
Initial Fill of Compressor Oil, Manual Drain Valve, Motor Starter Not Included, Oil Site Glass, Precision Bearing, Pressure Gauge, Pressure Relief Valve
Input Voltage - Air Compressor
208 to 240V AC, 480V AC
Item - Air Compressor
Stationary Air Compressor
Lubrication Type - Air compressor
Pressure Lubricated
Motor Type
Open Dripproof
Number of Stages - Air Compressor
2
Off Pressure Switch Setting
175 psi
On Pressure Switch Setting
140
Overall Height
75 in
Overall Length
35 in
Overall Width
27 in
Phase - Electrical
3
Pump Location - Air Compressor
Tank Mounted
Pump Oil Capacity
2 qt
Pump RPM
710
Standards
ASME, California Code 462(L)(2), EISA
Style - Air Compressor
Simplex
Tank Size - Air Compressor
80 gal
Tank Style - Air Compressor
Vertical
dBA @ 3 Feet
81
