OEM#: 5204-2RSNew OEM Original Outright

DOUBLE ROW ANGULAR CONTACT BALL BEARING, DOUBLE SEALED, OD 47MM, BORE 20MM, METRIC by SMT CORP

Your price:
$28.14 eachEstimated to ship by 11/29 if ordered before 10:30 AM EST
HomeSMT CORP52042rs
DOUBLE ROW ANGULAR CONTACT BALL BEARING, DOUBLE SEALED, OD 47MM, BORE 20MM, METRIC by SMT CORP
DOUBLE ROW ANGULAR CONTACT BALL BEARING, DOUBLE SEALED, OD 47MM, BORE 20MM, METRIC by SMT CORP

OEM#: 5204-2RS
DOUBLE ROW ANGULAR CONTACT BALL BEARING, DOUBLE SEALED, OD 47MM, BORE 20MM, METRIC by SMT CORP

New OEM Original Outright
Your price:
$28.14 each
Estimated to ship by 11/29 if ordered before 10:30 AM EST
Asset Information

Must purchase minimum of 2

ADD TO LIST
Product Overview

SMT 5204-2RS Double Row Angular Contact Ball Bearing, Double Sealed, OD 47mm, Bore 20mm, Metric

SMT 5200 series Double Row Angular Contact Ball Bearings consist of two single row angular contact ball bearings matched Back to Back arrangement, with inner and outer rings integrated. These bearings have the same bores and outside diameters as the corresponding bearings, 6200 series. SMT 5200 series are suitable for increased axial and radial rigidity in applications that design limits space. The contact angle is 30 degree inverted outside.

Technical Specs
P/N: 5204-2RS Key Specs
Item
DOUBLE ROW ANGULAR CONTACT BALL BEARING, DOUBLE SEALED, OD 47MM, BORE 20MM, METRIC
OEM
SMT CORP
OEM #
5204-2RS
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Type
Double Sealed
Bore Diameter Millimeters
20
Cage Material
Carbon Steel
Contact Angle
30
Country of Origin
Japan
Dynamic Load Rating (N)
19000
Grease Rpm
9000
Housing Corner Radius Max (Mm)
1
Lubrication Type
Shell Alvania S2, Prepacked
Operating Temperature
-13 to 212°F
Outer Diameter Millimeters
47
Shaft Fillet Corner Radius Max (Mm)
1
Static Load Rating (N)
12100
Tolerance
ISO Normal
Width Millimeters
20.6

SMT 5204-2RS Double Row Angular Contact Ball Bearing, Double Sealed, OD 47mm, Bore 20mm, Metric

SMT 5200 series Double Row Angular Contact Ball Bearings consist of two single row angular contact ball bearings matched Back to Back arrangement, with inner and outer rings integrated. These bearings have the same bores and outside diameters as the corresponding bearings, 6200 series. SMT 5200 series are suitable for increased axial and radial rigidity in applications that design limits space. The contact angle is 30 degree inverted outside.
