OEM#: SF-29New OEM Original Outright

FLANGE BEARING 4-BOLT BALL 1-13/16 BORE by Sealmaster

Your price:
$807.81 eachEstimated to ship by 12/06 if ordered before 4:30 PM EST
HomeSealmastersf29
FLANGE BEARING 4-BOLT BALL 1-13/16 BORE by Sealmaster
FLANGE BEARING 4-BOLT BALL 1-13/16 BORE by Sealmaster

OEM#: SF-29
FLANGE BEARING 4-BOLT BALL 1-13/16 BORE by Sealmaster

New OEM Original Outright
Your price:
$807.81 each
Estimated to ship by 12/06 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: SF-29 Key Specs
Item
FLANGE BEARING 4-BOLT BALL 1-13/16 BORE
OEM
Sealmaster
OEM #
SF-29
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Housing Material Type
Cast Iron
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Sealmaster GoldPlex-HP or NLGI #2 Equivalent
Bolt Hole Center-to-Center
4 3/8 in
Bolt Size
9/16 in
Bore Dia.
1 13/16 in
Dimension A
5 5/8 in
Dimension B
4 3/8 in
Dimension C
9/16 in
Dimension D
1 9/16 in
Dimension E
2 5/32 in
Dimension F
19/32 in
Dimension G
19/32 in
Dimension H
2 5/32 in
Dimension J
4 9/16 in
Dimension L
2 15/32 in
Dimension M
1 9/32 in
Dimension N
3/4 in
Dynamic Load Capacity
7,889 lb
Finish
Black Oxide
Mounted Bearing Item
4-Bolt Flange Bearing
Overall Height
5 5/8 in
Overall Length
5 5/8 in
Overall Width
2 5/32 in
Series
SF
Shaft Locking Type
Set Screw
Static Load Capacity
5,216 lb
Temp. Range
-20 Degrees to 220 Degrees F
