OEM#: 4301.0501New OEM Original Outright

50HZ C14 MALE APPLIANCE INLET POWER ENTRY MODULE - BLACK by Schurter

Your price:
$9.20 eachEstimated to ship by 12/27 if ordered before 6:30 PM EST
50HZ C14 MALE APPLIANCE INLET POWER ENTRY MODULE - BLACK by Schurter
50HZ C14 MALE APPLIANCE INLET POWER ENTRY MODULE - BLACK by Schurter

OEM#: 4301.0501
50HZ C14 MALE APPLIANCE INLET POWER ENTRY MODULE - BLACK by Schurter

New OEM Original Outright
Your price:
$9.20 each
Estimated to ship by 12/27 if ordered before 6:30 PM EST
Asset Information
Product Overview

  • Panel mount: Screw-on version from front or rear side, snap-in version front side
  • 3 Functions: Appliance Inlet Protection class I, Fuseholder for fuse-links 5 x 20 mm 1 or 2 pole, with or without voltage selector (step switch)
  • V-Lock notch standard
  • Meets the requirements of IEC 60335-1 for appliances in unattended use. This includes the enhanced requirements of glow wire tests acc. to IEC 60695-2-11 or -12 &-13
  • Quick connect terminals 4.8 x 0.8 mm
  • Plug removal necessary for fuse-link replacement
  • Suitable for use in equipment according to IEC/UL 62368-1

Features
  • Panel mount: Screw-on version from front or rear side, snap-in version front side
  • 3 Functions: Appliance Inlet Protection class I, Fuseholder for fuse-links 5 x 20 mm 1 or 2 pole, with or without voltage selector (step switch)
  • V-Lock notch standard
  • Meets the requirements of IEC 60335-1 for appliances in unattended use. This includes the enhanced requirements of glow wire tests acc. to IEC 60695-2-11 or -12 &-13
  • Quick connect terminals 4.8 x 0.8 mm
  • Plug removal necessary for fuse-link replacement
  • Suitable for use in equipment according to IEC/UL 62368-1
Technical Specs
P/N: 4301.0501 Key Specs
Item
50HZ C14 MALE APPLIANCE INLET POWER ENTRY MODULE - BLACK
OEM
Schurter
OEM #
4301.0501
Condition
New OEM Original
Returnable
No
Warranty
As Is
Amps
10A
Certifications
RoHS, CSA, UL, VDE
Color
Black
Connector
C14 Male
Degree of Protection
IP40
Frequency
50/60 HZ
Material
Thermoplastic
Mounting Type
Panel Mount/Screw
Number of Poles
2
Operating Temperature Range
-25° - 70°C
Panel Mounting
Screw
Panel Thickness
0.315 IN
Terminal Type
4.8 x 0.8mm Quick Connect
Volts
250 VAC
Equivalents

  • Panel mount: Screw-on version from front or rear side, snap-in version front side
  • 3 Functions: Appliance Inlet Protection class I, Fuseholder for fuse-links 5 x 20 mm 1 or 2 pole, with or without voltage selector (step switch)
  • V-Lock notch standard
  • Meets the requirements of IEC 60335-1 for appliances in unattended use. This includes the enhanced requirements of glow wire tests acc. to IEC 60695-2-11 or -12 &-13
  • Quick connect terminals 4.8 x 0.8 mm
  • Plug removal necessary for fuse-link replacement
  • Suitable for use in equipment according to IEC/UL 62368-1

  • 70080701: Byron Medical, Inc.: Item Replacement
