OEM#: PMP12K17GRNew OEM Original Outright

AIR COMPRESSOR PUMP 1 STAGE 3 HP by Rolair

Your price:
$625.99 each
$633.35 Savings: $7.36 (1%)
Estimated to ship by 12/09 if ordered before 4:30 PM EST
HomeRolairpmp12k17gr
AIR COMPRESSOR PUMP 1 STAGE 3 HP by Rolair
AIR COMPRESSOR PUMP 1 STAGE 3 HP by Rolair

OEM#: PMP12K17GR
AIR COMPRESSOR PUMP 1 STAGE 3 HP by Rolair

New OEM Original Outright
Your price:
$625.99 each
$633.35 Savings: $7.36 (1%)
Estimated to ship by 12/09 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: PMP12K17GR Key Specs
Item
AIR COMPRESSOR PUMP 1 STAGE 3 HP
OEM
Rolair
OEM #
PMP12K17GR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Avg. Pump Life
10,000 hr
Bore Dia.
2 33/64 in
Construction
Cast Iron
Finish
Painted Green
Flywheel Dia.
11 in
Flywheel Included
Yes
Free Air CFM @ Max. Pressure
10.1, 8.5
Groove Quantity
1
Groove Section
A
HP
1 1/2 hp, 3 hp
Lubrication Type
Splash Lubricated
Max. Pressure
150 psi
Mounting Pattern
7-1/16 in W x 5-3/16 in D
NPT Outlet
1/2 in
Number of Cylinders
2
Number of Stages
1
Oil Capacity
34 oz
Overall Depth
12 in
Overall Height
15 in
Overall Width
11 in
Pump RPM
1,000, 1,200
Rotation
CCW
Sheave Size @ 1725 RPM
6 3/8 in, 7 35/64 in
Sheave Size @ 3450 rpm
2 1/4 in
Stroke Length
2 in
Valve Material
Stainless Steel
Valve Type
Reed
