OEM#: UH1026V1New OEM Original Outright

UNIT HEATER MOTOR 1/4 HP 1075 115 V 48Y by Regal Beloit America, Inc. (Century Electric Motors)

Your price:
$250.00 each
$260.98 Savings: $10.98 (4%)
Ship date will be provided after ordering
HomeRegal Beloit America, Inc. (Century Electric Motors)uh1026v1
UNIT HEATER MOTOR 1/4 HP 1075 115 V 48Y by Regal Beloit America, Inc. (Century Electric Motors)
UNIT HEATER MOTOR 1/4 HP 1075 115 V 48Y by Regal Beloit America, Inc. (Century Electric Motors)

OEM#: UH1026V1
UNIT HEATER MOTOR 1/4 HP 1075 115 V 48Y by Regal Beloit America, Inc. (Century Electric Motors)

New OEM Original Outright
Your price:
$250.00 each
$260.98 Savings: $10.98 (4%)
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: UH1026V1 Key Specs
Item
UNIT HEATER MOTOR 1/4 HP 1075 115 V 48Y
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
UH1026V1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Dirty, Noncombustible Environments, Unit Heaters and Other Shaft-mounted Fan and Blower Equipment in Dusty
Body Diameter
5-5/8 in
Duty
Continuous
Frame
48Y
Full Load Amps
4.9
HP
1/4 in
Hz
60
Includes
2 Mounting Clamp Assemblies, 5 MFD 370 V AC Capacitor, Four 8-32 Dummy Studs, Mounting Base, Resilient Rings
Ins. Class
B
Length Less Shaft
5-3/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Efficiency Group
Energy Efficient
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Type
Cradle Base
Motor Service Factor
1
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Unit Heater
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in, 4-1/2 in x 2-9/16 in
Nameplate RPM
1075
Number of Speeds
1
Overall Length
10-3/8 in
Phase
1
Ring Diameter
2-1/2 in
Ring to Ring Center
4-15/16 in
Shaft Diameter
1/2 in
Shaft Length
5 in
Standards
CSA Certified (LR43341/LR4642), UL Recognized (E46412/E49807)
Voltage
115
Voltage Compatibility
115, 120
