OEM#: H667V1New OEM Original Outright
CONDENSER FAN MOTOR 1140 RPM 1 HP by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$509.79 each $528.26 Savings: $18.47 (3%)
Estimated to ship by 10/23 if ordered before 5:30 PM EST
OEM#: H667V1CONDENSER FAN MOTOR 1140 RPM 1 HP by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$509.79 each
$528.26 Savings: $18.47 (3%)
Ready to ShipEstimated to ship by 10/23 if ordered before 5:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: H667V1 Key Specs
Item
CONDENSER FAN MOTOR 1140 RPM 1 HP
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
H667V1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Condenser Fan
Body Diameter
6-5/8 in
Bolt Circle Diameter
5-15/16 in
Capacitor Required
No
Duty
Continuous
Frame
56Y
Full Load Amps
4.3-4.6/2.3
HP
1
Hz
60
Ins. Class
B
Lead Length
6 in
Length Less Shaft
10-1/2 in
Manufacturers Warranty Length
1 yr
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
3-Phase
Motor Enclosure Design
Open
Motor Mounting Position
Vertical Shaft Up
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Keyed with Single Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
4-3/16 in x 4-3/16 in
Nameplate RPM
1140
Nominal Efficiency
72.7 %
Number of Speeds
1
Overall Length
16-1/2 in
Phase
3
Shaft Diameter
5/8 in
Shaft Length
6 in
Standards
UL (E6312), CSA (LR2025)
Stud Quantity
4
Stud Size
10-32 x 1 in
Voltage
200-230/460
