OEM#: 9716New OEM Original Outright

MOTOR PSC 1/4 HP 1625 RPM 115V 42Y OAO by Regal Beloit America, Inc. (Century Electric Motors)

Your price:
$329.82 eachShip date will be provided after order confirmation.
MOTOR PSC 1/4 HP 1625 RPM 115V 42Y OAO by Regal Beloit America, Inc. (Century Electric Motors)
MOTOR PSC 1/4 HP 1625 RPM 115V 42Y OAO by Regal Beloit America, Inc. (Century Electric Motors)

OEM#: 9716
MOTOR PSC 1/4 HP 1625 RPM 115V 42Y OAO by Regal Beloit America, Inc. (Century Electric Motors)

New OEM Original Outright
Your price:
$329.82 each
Ship date will be provided after order confirmation.
Asset Information
Are you an existing customer? Sign in to access your account.
Technical Specs
P/N: 9716 Key Specs
Item
MOTOR PSC 1/4 HP 1625 RPM 115V 42Y OAO
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
9716
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Blowers, Fans and Air Circulators
Body Diameter
5 in
Bolt Circle Diameter
4-5/8 in
Capacitor Required
2MDV6
Duty
Continuous
Frame
42Y
Full Load Amps
4
HP
1/4 in
Hz
60
Includes
Resilient Mounting Ring
Ins. Class
B
Length Less Shaft
6-3/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
Horizontal
Motor Mounting Type
Ring
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Location
Both Ends
Mounting Stud Pattern
3-1/4 in x 3-1/4 in
Nameplate RPM
1625
Number of Speeds
3
Phase
1
Resilient Ring Diameter
2-1/2 in
Ring to Ring Center
5-13/16 in
Shaft Diameter
1/2 in
Shaft Length
5-1/4 in
Standards
CSA Certified, UL Recognized
Stud Size
#8-32
Voltage
115
Voltage Compatibility
115, 120
