OEM#: 752ANew OEM Original Outright
MOTOR PSC 1/4 HP 1075 RPM 115V 48Y OAO by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$256.44 each
OEM#: 752AMOTOR PSC 1/4 HP 1075 RPM 115V 48Y OAO by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$256.44 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 752A Key Specs
Item
MOTOR PSC 1/4 HP 1075 RPM 115V 48Y OAO
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
752A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Blowers, Fans and Air Circulators
Body Diameter
5-5/8 in
Capacitor Required
2MDV4
Country of Origin
Mexico
Duty
Continuous
Frame
48Y
Full Load Amps
3.9
HP
1/4 in
Hz
60
Includes
Reversing Plug
Ins. Class
B
Length Less Shaft
5-3/16 in
Max Ambient Temperature
50 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
Horizontal
Motor Mounting Type
T-Flex
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Number of Speeds
4
Overall Length
9-7/8 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
5-1/2 in
Standards
CSA Certified (LR43341/LR12645), UL Recognized (E46412/E49807)
Voltage
115
