OEM#: FTG-16-A-E-18New OEM Original Outright

FLEXIBLE METAL HOSE ASSEMBLY 1 I.D.18 by Penflex

Your price:
$252.46 eachShip date will be provided after ordering
HomePenflexftg16ae18
FLEXIBLE METAL HOSE ASSEMBLY 1 I.D.18 by Penflex
FLEXIBLE METAL HOSE ASSEMBLY 1 I.D.18 by Penflex

OEM#: FTG-16-A-E-18
FLEXIBLE METAL HOSE ASSEMBLY 1 I.D.18 by Penflex

New OEM Original Outright
Your price:
$252.46 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: FTG-16-A-E-18 Key Specs
Item
FLEXIBLE METAL HOSE ASSEMBLY 1 I.D.18
OEM
Penflex
OEM #
FTG-16-A-E-18
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Compatible Chemicals
Ethyl (Ethanol), Methyl (Methanol), Antifreeze (Coolant), Gasoline, Kerosene, Diesel Fuel, Hydraulic Fluid (Petroleum), Hydraulic Fluid (Synthetic), Ethyl Acetate, Biodiesel, Formaldehyde, Ammonium Hydroxide, Potassium Hydroxide (50%), Fresh Water, M
Country of Origin
USA
Dynamic Min Bend Radius (Inches)
9
Hose Cover Material
304 Stainless Steel
Hose Fitting A Material
Carbon Steel
Hose Fitting A Size
1-1/16 in
Hose Fitting A Type
FJIC
Hose Fitting B Material
Carbon Steel
Hose Fitting B Size
1 in
Hose Fitting B Type
MNPT
Hose Inside Diameter
1 in
Hose Length
18 in
Hose Tube Material
321 Stainless Steel
Max Working Pressure @ 70 F
571 psi
Not Recommended Chemicals
Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Chromic Acid 5%, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 50%, Citric Acid 50%, Formic Acid, Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrochloric/Muriatic Ac
Standards
ISO 10380 TYPE 2 COMPLIANT; ASME B31.1 & B31.3; ASTM A240, ASTM A580, ASME BPV SEC. IX; COMPLIES TO PED 97/23/EC CATEGORIES I, II, III, V
Temperature Range
1500 Degrees F
