OEM#: 70254New OEM Original Outright

INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-023 TEMP. RANGE -30-100F W/ NEMA 4X by PECO

Your price:
$92.39 eachEstimated to ship by 10/23 if ordered before 10:30 AM EST
HomePECO70254
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-023 TEMP. RANGE -30-100F W/ NEMA 4X by PECO
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-023 TEMP. RANGE -30-100F W/ NEMA 4X by PECO

OEM#: 70254
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-023 TEMP. RANGE -30-100F W/ NEMA 4X by PECO

New OEM Original Outright
Your price:
$92.39 each
Ready to shipReady to Ship
Estimated to ship by 10/23 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 70254 Key Specs
Item
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-023 TEMP. RANGE -30-100F W/ NEMA 4X
OEM
PECO
OEM #
70254
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps @ 120V
16 AMP FLA; 80A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 208V
13.2 AMP FLA; 66A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 240V
12 AMP FLA; 60A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 277V
110 AMP FLA; 50A LRA; 22 AMP Non-Inductive; 125 VA Pilot Duty
Application
Heat & Cool
Bulb
Coiled Air - Stainless
Capillary Length Feet
Coiled Capillary
Country of Origin
China
Differential Temperature °F
6
For Use With
Refrigeration / Industrial / Agricultural
Limited Warranty Years
1
Listing, Rating, Certification
UL, CSA
Nema Rating
4X
Physical Dimensions
3.1"W x 6.5"H x 2.5"D
Power Type
Hardwired
Stages
Single
Switch Action
SPDT
Temperature - Operating Range °F
-30 to 100
Temperature Control Range °F
30 to 100
Type
Mechanical
Voltage
277 / 240 / 208 / 120 / 24
