OEM#: 68471New OEM Original Outright

INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-001 TEMP. RANGE 40-110F W/ NEMA 4X by PECO

Your price:
$63.59 eachEstimated to ship by 12/26 if ordered before 10:30 AM EST
HomePECO68471
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-001 TEMP. RANGE 40-110F W/ NEMA 4X by PECO
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-001 TEMP. RANGE 40-110F W/ NEMA 4X by PECO

OEM#: 68471
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-001 TEMP. RANGE 40-110F W/ NEMA 4X by PECO

New OEM Original Outright
Your price:
$63.59 each
Estimated to ship by 12/26 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 68471 Key Specs
Item
INDUSTRIAL COILED TEMPERATURE CONTROLLER TF115-001 TEMP. RANGE 40-110F W/ NEMA 4X
OEM
PECO
OEM #
68471
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps @ 120V
16 AMP FLA; 80A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 208V
13.2 AMP FLA; 66A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 240V
12 AMP FLA; 60A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 277V
110 AMP FLA; 50A LRA; 22 AMP Non-Inductive; 125 VA Pilot Duty
Application
Heat & Cool
Bulb
Coiled Air - Stainless
Capillary Length Feet
Coiled Capillary
Country of Origin
China
Differential Temperature °F
3
For Use With
Refrigeration / Industrial / Agricultural
Limited Warranty Years
1
Listing, Rating, Certification
UL, CSA
Nema Rating
4X
Physical Dimensions
3.1"W x 6.5"H x 2.5"D
Power Type
Hardwired
Stages
Single
Switch Action
SPDT
Temperature - Operating Range °F
40 to 110
Temperature Control Range °F
40 to 110
Type
Mechanical
Voltage
277 / 240 / 208 / 120 / 24
