P/N: 68426 Key Specs
Item
INDUSTRIAL TEMPERATURE CONTROLLER TRF115-005 TMP. RANGE 0-120F RMT. BULB NEMA 4X
Condition
New OEM Original
Amps @ 120V
16 AMP FLA; 80A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 208V
13.2 AMP FLA; 66A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 240V
12 AMP FLA; 60A LRA; 25 AMP Non-Inductive; 125 VA Pilot Duty
Amps @ 277V
110 AMP FLA; 50A LRA; 22 AMP Non-Inductive; 125 VA Pilot Duty
Bulb
5 Foot Stainless Remote
Differential Temperature °F
3
For Use With
Refrigeration / Industrial / Agricultural
Listing, Rating, Certification
UL, CSA
Physical Dimensions
3.1"W x 6.5"H x 2.5"D
Temperature - Operating Range °F
0 to 120
Temperature Control Range °F
0 to 120
Voltage
277 / 240 / 208 / 120 / 24
