OEM#: 6305New OEM Original Outright

DEEP GROOVE BALL BEARING - OPEN 25MM BORE, 62MM OD by ORS Bearings

Your price:
$6.98 eachEstimated to ship by 11/29 if ordered before 10:30 AM EST
HomeORS Bearings6305
DEEP GROOVE BALL BEARING - OPEN 25MM BORE, 62MM OD by ORS Bearings
DEEP GROOVE BALL BEARING - OPEN 25MM BORE, 62MM OD by ORS Bearings

OEM#: 6305
DEEP GROOVE BALL BEARING - OPEN 25MM BORE, 62MM OD by ORS Bearings

New OEM Original Outright
Your price:
$6.98 each
Estimated to ship by 11/29 if ordered before 10:30 AM EST
Asset Information

Must purchase minimum of 7

ADD TO LIST
Product Overview

ORS 6305 Deep Groove Ball Bearing - Open 25mm Bore, 62mm OD

ORS Deep Groove Ball Bearings. Deep Grove Ball Bearings, often called Radial Ball Bearings, accommodate radial and axial loads, and are capable of operating at higher speeds. Due to these capabilities, they are the most widely used type of bearing. ORS Deep Groove Ball Bearings are made of AISI 52100 grade steel heat-stabilized to 300°F, in ABEC 1 tolerance (ISO Normal) and with C3 radial clearance. All of ORS bearings are 100% noise tested and produced to EMQ. Forgings and heat treatment are done in house. ORS is offering Double Sealed and Double Shielded bearings with Snap Ring for most sizes. ORS Bearings Inc. was established in 1982 with the license of Steyr Waelzlager of Austria, and headquartered in Ankara, Turkey with its 1,000,000 square foot production facility. The company has been granted numerous awards and certificates such as ISO 9001:2008, ISO/TS 16949:2009, ISO 14001, ISO/IEC 27001:2005, OHSAS 18001, FORD Q1 and many more. ORS bearings are commonly used in electric motors, appliances, fans, pumps, machine tool, agriculture, clutches, conveyors, food processing, textile and many other equipment and machinery.

Technical Specs
P/N: 6305 Key Specs
Item
DEEP GROOVE BALL BEARING - OPEN 25MM BORE, 62MM OD
OEM
ORS Bearings
OEM #
6305
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Type
Open
Bore Diameter Millimeters
25
Cage Material
Pressed steel
Country of Origin
Turkey
Dynamic Load (Kn)
23.62
Housing Corner Radius Max (Mm)
1.1
Internal Radial Clearance
C3
Max Speed / Grease (Rpm)
10000
Max Speed / Oil (Rpm)
12000
Operating Temperature
- 20 / + 300°F
Outer Diameter Millimeters
62
Shaft Fillet Corner Radius Max (Mm)
1.1
Static Load (Kn)
12.13
Tolerance
ISO Normal
Width Millimeters
17

ORS 6305 Deep Groove Ball Bearing - Open 25mm Bore, 62mm OD
