OEM#: TDX100M120/208New OEM Original Outright
SURGE PROTECTION DEVICE 120/208V WYE 3PH by Nvent Erico
Your price:
$2,346.57 eachEstimated to ship by 11/29 if ordered before 4:30 PM EST
OEM#: TDX100M120/208SURGE PROTECTION DEVICE 120/208V WYE 3PH by Nvent Erico
New OEM Original Outright
Your price:
$2,346.57 each
Estimated to ship by 11/29 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: TDX100M120/208 Key Specs
Item
SURGE PROTECTION DEVICE 120/208V WYE 3PH
OEM
Nvent Erico
OEM #
TDX100M120/208
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps
100 K
Basic Material
Metallic
Chase Nipple Size
3/4 in
Color
Gray
Country of Origin
China
Depth
3.07 in
Enclosure Material
Metal
Enclosure NEMA Rating
4
Filtering
No
IP Rating
65
Includes
Audible Alarm, Status Indicator Flag, Voltage Free Contact, Voltage Presence LED
Length
9.45 in
Lightning Impulse Current
12.5 kA
Max Continuing Operating Voltage
170/276V AC
Max Operating Temperature
176 Degrees F
Max Surge Current per Mode
100kA
Max Surge Current per Phase
100 kA
Min Operating Temperature
-40 Degrees F
Modes of Protection
L-G, L-L, L-N, N-G
Modular
Yes
Mounting Location
Externally Mounted
Mounting Style
Chase Nipple/Panel
Nominal Discharge Current
50 kA
Number of Poles
4
Number of Wires
4 Wires + Ground
Phase
3
Short Circuit Current Rating
200kA
Standards
ANSI/IEEE, C-Tick, CE, IEC 61643-1, UL 1449 Edition 3 Type 1/2
System Connection
Parallel
UL SPD Type
Type 1/2
Voltage
120/208V AC Wye
Voltage Protection Rating
600V (L-N, N-G), 700V (L-G), 1000V (L-L)
Width
3.31 in
Wire Gauge
10 AWG
