OEM#: TDX200C120/240New OEM Original Outright

SURGE PROTECTION DEVICE 120/240VAC 1PH by Nvent Erico

Your price:
$1,960.84 each
$2,010.16 Savings: $49.32 (2%)
Estimated to ship by 11/29 if ordered before 4:30 PM EST
HomeNvent Ericotdx200c120240
SURGE PROTECTION DEVICE 120/240VAC 1PH by Nvent Erico
SURGE PROTECTION DEVICE 120/240VAC 1PH by Nvent Erico

OEM#: TDX200C120/240
SURGE PROTECTION DEVICE 120/240VAC 1PH by Nvent Erico

New OEM Original Outright
Your price:
$1,960.84 each
$2,010.16 Savings: $49.32 (2%)
Estimated to ship by 11/29 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: TDX200C120/240 Key Specs
Item
SURGE PROTECTION DEVICE 120/240VAC 1PH
OEM
Nvent Erico
OEM #
TDX200C120/240
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps
200 K
Basic Material
Metallic
Chase Nipple Size
3/4 in
Color
Gray
Country of Origin
China
Depth
3.07 in
Enclosure Material
Metal
Enclosure NEMA Rating
4
Filtering
No
IP Rating
65
Includes
LED Status Indicator, Voltage Free Contact
Length
11 in
Lightning Impulse Current
25 kA
Max Continuing Operating Voltage
170/276V AC
Max Operating Temperature
176 Degrees F
Max Surge Current per Mode
200kA
Max Surge Current per Phase
200 kA
Min Operating Temperature
-40 Degrees F
Modes of Protection
L-G, L-L, L-N, N-G
Modular
Yes
Mounting Location
Externally Mounted
Mounting Style
Chase Nipple/Panel
Nominal Discharge Current
20 kA
Number of Poles
3
Number of Wires
3 Wires + Ground
Phase
1
Short Circuit Current Rating
200kA
Standards
ANSI/IEEE, C-Tick, CE, IEC 61643-1, UL 1449 Edition 3 Type 1/2
System Connection
Parallel
UL SPD Type
Type 1/2
Voltage
120/240V AC
Voltage Protection Rating
600V (L-G, L-N, N-G), 1000V (L-L)
Width
3.31 in
Wire Gauge
10 AWG
