OEM#: UCFLU-1.9/16MNew OEM Original Outright

FLANGE BEARING 2-BOLT BALL 1-9/16 BORE by NTN

Your price:
$196.11 eachShip date will be provided after ordering
HomeNTNucflu1916m
FLANGE BEARING 2-BOLT BALL 1-9/16 BORE by NTN
FLANGE BEARING 2-BOLT BALL 1-9/16 BORE by NTN

OEM#: UCFLU-1.9/16M
FLANGE BEARING 2-BOLT BALL 1-9/16 BORE by NTN

New OEM Original Outright
Your price:
$196.11 each
Ship date will be provided after ordering
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: UCFLU-1.9/16M Key Specs
Item
FLANGE BEARING 2-BOLT BALL 1-9/16 BORE
OEM
NTN
OEM #
UCFLU-1.9/16M
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Housing Material Type
Cast Iron
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Shell Alvania #3 or NLGI #3 Equivalent
Bolt Hole Center-to-Center
5 21/32 in
Bolt Size
7/16 in
Bore Dia.
1 9/16 in
Dimension A
1 17/32 in
Dimension Ao
29/64 in
Dimension B
1 15/16 in
Dimension D
1 9/16 in
Dimension H
6 25/32 in
Dimension J
5 21/32 in
Dimension L
4 1/8 in
Dimension N
33/64 in
Dimension S
3/4 in
Dynamic Load Capacity
6,550 lb
Finish
Painted
Mounted Bearing Item
2-Bolt Flange Bearing
Overall Height
2 9/64 in
Overall Length
6 25/32 in
Overall Width
4 1/8 in
Series
Standard Duty
Shaft Locking Type
Set Screw
Static Load Capacity
4,000 lb
Temp. Range
-20 Degrees to 250 Degrees F
