OEM#: SUCFPL207-20C0FG1New OEM Original Outright

FLANGE BEARING 4-BOLT 1-1/4 BORE DIA by NTN

Your price:
$586.96 eachEstimated to ship by 04/22 if ordered before 1:30 PM EST
HomeNTNsucfpl20720c0fg1
FLANGE BEARING 4-BOLT 1-1/4 BORE DIA by NTN
FLANGE BEARING 4-BOLT 1-1/4 BORE DIA by NTN

OEM#: SUCFPL207-20C0FG1
FLANGE BEARING 4-BOLT 1-1/4 BORE DIA by NTN

New OEM Original Outright
Your price:
$586.96 each
Estimated to ship by 04/22 if ordered before 1:30 PM EST
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: SUCFPL207-20C0FG1 Key Specs
Item
FLANGE BEARING 4-BOLT 1-1/4 BORE DIA
OEM
NTN
OEM #
SUCFPL207-20C0FG1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Housing Material Type
PBT
Bearing Insert Material
440C Stainless Steel
Bearing Insert Type
Ball
Bearing Lubrication
FDA/USDA-H1 Solid Grease
Bolt Hole Center-to-Center
3 5/8 in
Bolt Size
1/2 in
Bore Dia.
1 1/4 in
Dynamic Load Capacity
4,520 lb
Finish
Unfinished
Includes
(2) Open End Caps
Mounted Bearing Item
4-Bolt Flange Bearing
Overall Height
4 5/8 in
Overall Length
4 5/8 in
Overall Width
2 1/2 in
Series
FPL-FG1
Shaft Locking Type
Set Screw
Standards
NSF H1 Registered
Static Load Capacity
3,510 lb
Temp. Range
14 Degrees to 212 Degrees F
