OEM#: SK1SI63Y-180TC-7.5:1New OEM Original Outright

SPEED REDUCER RIGHT ANGLE 180TC 7.5 1 by Nord

Your price:
$923.80 eachEstimated to ship by 12/06 if ordered before 4:30 PM EST
HomeNordsk1si63y180tc751
SPEED REDUCER RIGHT ANGLE 180TC 7.5 1 by Nord
SPEED REDUCER RIGHT ANGLE 180TC 7.5 1 by Nord

OEM#: SK1SI63Y-180TC-7.5:1
SPEED REDUCER RIGHT ANGLE 180TC 7.5 1 by Nord

New OEM Original Outright
Your price:
$923.80 each
Estimated to ship by 12/06 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: SK1SI63Y-180TC-7.5:1 Key Specs
Item
SPEED REDUCER RIGHT ANGLE 180TC 7.5 1
OEM
Nord
OEM #
SK1SI63Y-180TC-7.5:1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearings
Ball
Bore Dia.
1 219/500 in
Finish
Tural
Frame
180TC
Gear Type
Worm
Housing Material
Aluminum
Input RPM
1,750
Lubrication
Food Grade Synthetic
Max. Input HP
5.06 hp
Max. Output Torque
1,230 in-lb
Mounting
Universal Foot and Flange-Mount
Nominal Output RPM
233
Nominal Ratio
7.5:1
Number of Stages
1
Output Shaft Dia.
1 1/8 in
Output Shaft Height
2 53/64 in
Output Torque @ 1 HP
257 in-lb
Output Torque @ 1.5 HP
381 in-lb
Output Torque @ 1/2 HP
124 in-lb
Output Torque @ 1/3 HP
81 in-lb
Output Torque @ 1/4 HP
63 in-lb
Output Torque @ 1/6 HP
40 in-lb
Output Torque @ 2 HP
504 in-lb
Output Torque @ 3 HP
756 in-lb
Output Torque @ 3/4 HP
186 in-lb
Output Torque @ 4 HP
1,217 in-lb
Overall Length
4.61 in
Overhung Load
1,415 lb
Pinion Material
Hardened Steel
Rotation
Reversible
Seal Type
Double Lip
Shaft Orientation
Right Angle
Single/Double Output/Universal
Universal
Solid/Hollow Output Shaft
Solid/Hollow
Speed Reducer Type
Right Angle
Standards
IEC, NEMA
Worm Center Distance
2.48 in
Worm Gear Material
Fine-Grained Bronze Alloy
