OEM#: 23C6199New OEM Original Outright
QUICK ACTING MINIATURE FUSE KIT, 5 MM DIA, 800 MA TO 10 A, CERAMIC, 250 VAC, -55 TO 125 DEG C, 20 MM, SAFETY, MEETS CE, CSA, IEC 60127-2/1, by Newark / Element 14
Your price:
$377.78 eachEstimated to ship by 10/24 if ordered before 4:30 PM EST
OEM#: 23C6199QUICK ACTING MINIATURE FUSE KIT, 5 MM DIA, 800 MA TO 10 A, CERAMIC, 250 VAC, -55 TO 125 DEG C, 20 MM, SAFETY, MEETS CE, CSA, IEC 60127-2/1, by Newark / Element 14
New OEM Original Outright
Your price:
$377.78 each
Estimated to ship by 10/24 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Product Overview
FSF 5X20 fuse kit for quick sampling of customers and engineering design support. The fuse kit includes 18 fuse links out of which 9 fuse links are of SP 5x20 and 9 fuse links are of SPT 5x20 fuses types. It is used in primary protection in equipment.
- IEC standard, non resettable fuses, quick-acting F (SP 5x20), time-lag T (SPT 5x20) characteristic
- High breaking capacity, ceramic tube & nickel-plated copper alloy endcaps
- UL 248-14, CSA C22.2 No. 248.14, IEC 60127-2/1 (SP 5x20) and IEC 60127-2/5 (SPT 5x20) standards
- UL file number E41599, VDE number 40009397 (SP 5x20), VDE number 40014395 (SP 5x20) certified
- 250VAC rated voltage (SP-5x20), 250VAC, 300VDC rated voltage (SPT-5x20), 0.5 to 16A rated current
- 55/125/21 according to IEC 60068-1 climatic category
Includes
- Quick Acting
- Time Lag
- Ceramic
- Miniature
Technical Specs
P/N: 23C6199 Key Specs
Item
QUICK ACTING MINIATURE FUSE KIT, 5 MM DIA, 800 MA TO 10 A, CERAMIC, 250 VAC, -55 TO 125 DEG C, 20 MM, SAFETY, MEETS CE, CSA, IEC 60127-2/1,
OEM
Newark / Element 14
OEM #
23C6199
Condition
New OEM Original
Returnable
No
Warranty
As Is
Ambient air Temperature Range
-55°C - 125°C
Amps Range
800MA - 10A
Breaking Capacity Range
500 A - 1500 A
Certifications
RoHS
Current Rating
800 mA to 10 A
Diameter
5 mm
Length
0.78 IN
Material
Ceramic
Standards
CE, CSA, IEC 60127-2/1, ROHS, UL
Storage Temperature Range
0°C - 60°C
Temperature Rating
-55 to 125 Deg C
Voltage Rating
250 VAC
FSF 5X20 fuse kit for quick sampling of customers and engineering design support. The fuse kit includes 18 fuse links out of which 9 fuse links are of SP 5x20 and 9 fuse links are of SPT 5x20 fuses types. It is used in primary protection in equipment.
- IEC standard, non resettable fuses, quick-acting F (SP 5x20), time-lag T (SPT 5x20) characteristic
- High breaking capacity, ceramic tube & nickel-plated copper alloy endcaps
- UL 248-14, CSA C22.2 No. 248.14, IEC 60127-2/1 (SP 5x20) and IEC 60127-2/5 (SPT 5x20) standards
- UL file number E41599, VDE number 40009397 (SP 5x20), VDE number 40014395 (SP 5x20) certified
- 250VAC rated voltage (SP-5x20), 250VAC, 300VDC rated voltage (SPT-5x20), 0.5 to 16A rated current
- 55/125/21 according to IEC 60068-1 climatic category
