OEM#: 535-110New OEM Original Outright

LKG 610 10 LEAD ELECTRICAL SAFETY ANALYZER, 110 V by Netech Corp.

Your price:
$1,736.90 eachEstimated to ship by 12/31 if ordered before 12:30 PM EST
HomeNetech Corp.535110
LKG 610 10 LEAD ELECTRICAL SAFETY ANALYZER, 110 V by Netech Corp.
LKG 610 10 LEAD ELECTRICAL SAFETY ANALYZER, 110 V by Netech Corp.

OEM#: 535-110
LKG 610 10 LEAD ELECTRICAL SAFETY ANALYZER, 110 V by Netech Corp.

New OEM Original Outright
Your price:
$1,736.90 each
Estimated to ship by 12/31 if ordered before 12:30 PM EST
Asset Information
ADD TO LIST
Product Overview

LKG 610 Electrical Safety Analyzer is designed to test any piece of electrically operated patient care equipment. This full featured analyzer is microprocessor controlled and has a complete compliment of ten leads. LKG 610 measures line voltage, outlet polarity, device current, earth leakage current, chassis resistance, and case leakage current. In addition, it performs lead ISO tests and point-to-point measurements.

All tests are quickly and easily performed by selecting the appropriate test function key. Measurement results are displayed on the large LCD screen with measurement units clearly indicated by an LED. Large switches change the polarity, open and close neutral, and lift the ground. Ten universal lead connectors accept both snaps and any size posts. Calibrated test points are available to ensure performance accuracy and repeatability. Either AAMI or IEC 601-1 test loads may be selected. The receptacle is fused with an accessible 20A fuse and the tester itself is fused internally.

  • Fast, accurate, and portable
  • Easy to use
  • Large LCD display
  • Accessible line fuse
  • Calibrated test points
  • Selectable test loads
  • 15 and 20 amp capabilities
  • Point-to-point testing
  • Uses any test cable
  • 10 lead universal connector
  • Complies with both aami and iec 601-1 test loads
  • Power requirements: 110 VAC 50 - 60 Hz, 20 Amp or 220 VAC 10 Amp maximum rated for the test outlet and 0.1 Amps rated for the unit
  • LED unit of measure indicator
  • Controls: 12 Push Button Function Keys - Open/Closed, Neutral Switch Normal/Off/Reverse Polarity Switch, Momentary Ground Open Switch, 10 Universal Snap/Post ECG Connectors Test Load Selector Switch

Accuracy:

  • Resistance: +/- 2% +/- 1 LSD
  • Leakage: +/- 1% of FS DC to 1 KHz +/- 1 LSD, +/- 2% of FS 1 KHz to 100 KHz, +/- 4% of FS 100 kHz to 1 MHz
  • Instrument Current: +/- 2% +/- 1 LSD

Calibrated Test Points:

  • Reference Ground: 1 Ohm
  • Leakage: 200 microamp

Technical Specs
P/N: 535-110 Key Specs
Item
LKG 610 10 LEAD ELECTRICAL SAFETY ANALYZER, 110 V
OEM
Netech Corp.
OEM #
535-110
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Amps
20 A or 220 VAC
Display
LCD
Frequency
50 - 60 HZ
Instrument Current
0 - 19.99 A
Leakage Amps
0 - 1999 MA
Operating Range
59 to 95°F (15 to 35°C)
Relative Humidity
90% (max) at Temperature
Resistance
0 - 1999 MOhms
Storage Temperature
0 to 122°F ( -18 to 50°C)
Volts
110 VAC
Certifications
Minority OwnedMinority OwnedSBASBA
