OEM#: 5211ANew OEM Original Outright
UNIT BEARING MOTOR 1/15 HP 208-230V CWLE by Morrill
Your price:
$338.96 eachEstimated to ship by 01/09 if ordered before 4:30 PM EST
OEM#: 5211AUNIT BEARING MOTOR 1/15 HP 208-230V CWLE by Morrill
New OEM Original Outright
Your price:
$338.96 each
Estimated to ship by 01/09 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 5211A Key Specs
Item
UNIT BEARING MOTOR 1/15 HP 208-230V CWLE
OEM
Morrill
OEM #
5211A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
3-19/64 in
Bolt Circle Diameter
2-27/32 in
Country of Origin
Mexico
Frame
59
Full Load Amps
0.63
HP
1/15
Hz
60/50
Ins. Class
B
Length Less Shaft
3-3/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
ECM
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Frame Material
Steel
Motor Mounting Position
Horizontal or Vertical Shaft Up
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CWLE
Motor Sub Application
Refrigerator/Freezer
Motor Thermal Protection
Auto
Mounting Stud Length
29/64 in
Nameplate RPM
1550/800
Output Watts
50 W
Overall Length
6-27/64 in
Phase
1
Plug Type
Round 2 Pin
Shaft Diameter
5/16 in
Shaft Length
2-5/8 in
Standards
UL
Voltage
208-230
Voltage Compatibility
115/208-230, 208-230, 208-240
