OEM#: 240-SC-02-O(JAA)-50HNew OEM Original Outright

PRESSURE GAUGE 0 TO 50 IN H2O by Mid-West Instrument

Your price:
$1,451.48 eachEstimated to ship by 11/29 if ordered before 4:30 PM EST
HomeMid-West Instrument240sc02ojaa50h
PRESSURE GAUGE 0 TO 50 IN H2O by Mid-West Instrument
PRESSURE GAUGE 0 TO 50 IN H2O by Mid-West Instrument

OEM#: 240-SC-02-O(JAA)-50H
PRESSURE GAUGE 0 TO 50 IN H2O by Mid-West Instrument

New OEM Original Outright
Your price:
$1,451.48 each
Estimated to ship by 11/29 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 240-SC-02-O(JAA)-50H Key Specs
Item
PRESSURE GAUGE 0 TO 50 IN H2O
OEM
Mid-West Instrument
OEM #
240-SC-02-O(JAA)-50H
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Basic Gauge Case Material
Plastic
Basic Gauge Wetted Parts
Stainless Steel / Buna-N
Body Material
316 Stainless Steel
Contact Rating
0.25A, 125V AC/V DC
Country of Origin
USA
Dial Material
Engineered Plastic
Diaphragm Material
Buna-N
Differential Gauge Connection Size
1/4 in
Differential Gauge Connection Type
FNPT
Differential Pressure Gauge Type
Differential Pressure Gauge
Differential Pressure Range Units
in wc
Differential Pressure Range Value
0 to 50
Gauge Accuracy
+/-3-2-3%
Gauge Connection Location
Inline
Gauge Nominal Dial Size
4-1/2 in
Gauge Operating Temperature Range
-40 Degrees to 185 Degrees F
Gauge Primary Range Smallest Graduation
2
Includes
Installation and Operation Manual
Manufacturers Warranty Length
5 yr
Piston Material
Stainless Steel
Rated Total Pressure
1500 psi
Relay Type
SPDT
Scale Type
Pressure
Seal Material
Buna-N
Standards
25 and 30, 508, 698, ASME B1.201, ASME B40.1, CSA-C22.2 No. 14, EN13463-1, EN60079-0, EN60079-1, EN61241-0, EN61241-1, NEMA Std. No. 250, SAE J514, UL Std. No. 50, and 1203
