OEM#: Z411New OEM Original Outright
CLOSED-COUPLED PUMP MOTOR, 7.5HP, 230V, 1800RPM, 1PH, 215JM FR, DP by Marathon Motors
Your price:
$2,361.24 eachEstimated to ship by 10/31 if ordered before 10:30 AM EST
OEM#: Z411CLOSED-COUPLED PUMP MOTOR, 7.5HP, 230V, 1800RPM, 1PH, 215JM FR, DP by Marathon Motors
New OEM Original Outright
Your price:
$2,361.24 each
Estimated to ship by 10/31 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Closed-Coupled Pump Motor, Z411, 7.5HP, 230V, 1800RPM, 1PH, 215JM FR, DP
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Technical Specs
P/N: Z411 Key Specs
Item
CLOSED-COUPLED PUMP MOTOR, 7.5HP, 230V, 1800RPM, 1PH, 215JM FR, DP
OEM
Marathon Motors
OEM #
Z411
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
5.6
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6309
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6309
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
34.5
Fl Efficiency
84
Frame
215JM
Horsepower
7 1/2
Insulation Class
F
Ip Code
22
Is_Motor
Yes
Kva-Code
G
Model Number
215TBDW7029
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
L
Opposite End Bearing
6206
Opposite End Bearing Size
6206
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Cap Start Cap Run
Ul
Recognized Construction
Voltage
230
Weight
120
