OEM#: Y536New OEM Original Outright
INVERTER DUTY MOTOR, 143THTR5326, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV by Marathon Motors
Your price:
$744.53 eachShip date will be provided after ordering
OEM#: Y536INVERTER DUTY MOTOR, 143THTR5326, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV by Marathon Motors
New OEM Original Outright
Your price:
$744.53 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y536, 143THTR5326, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV
Designed for inverter or vector applications where up to a 1000:1 constant Torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Technical Specs
P/N: Y536 Key Specs
Item
INVERTER DUTY MOTOR, 143THTR5326, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV
OEM
Marathon Motors
OEM #
Y536
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
3/1.5
60 Hertz Fl Eff
84.00 Percent
60 Hertz Kw
0.75
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Catalog No.
Y536
Ce
Y
Csa
Y
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
143TC
Horsepower
3
Insulation Class
F
Inverter Speed Range
Constant 1000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
P
Model Number
143THTR5326
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
Recognized Construction and Protector
Voltage
230/460
Weight In Lbs.
42
Marathon Motors Inverter Duty Motor, Y536, 143THTR5326, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV
Designed for inverter or vector applications where up to a 1000:1 constant Torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
