OEM#: Y281New OEM Original Outright
INVERTER DUTY MOTOR, 56H17T15528, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, TENV by Marathon Motors
Your price:
$1,410.61 eachEstimated to ship by 11/06 if ordered before 10:30 AM EST
OEM#: Y281INVERTER DUTY MOTOR, 56H17T15528, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, TENV by Marathon Motors
New OEM Original Outright
Your price:
$1,410.61 each
Estimated to ship by 11/06 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y281, 56H17T15528, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, TENV
The Max+ incorporates low rotor inertia for fast starts, stops, ad reversals. Coupled with a encoder make this useful in applications traditionally served only by servo systems. The Max+ is also suitable for all applications where up to a 1000:1 Constant Torque speed range.
Technical Specs
P/N: Y281 Key Specs
Item
INVERTER DUTY MOTOR, 56H17T15528, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, TENV
OEM
Marathon Motors
OEM #
Y281
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
2.4/1.2
60 Hertz Fl Eff
82.50 Percent
60 Hertz Kw
0.56
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Catalog No.
Y281
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
56C
Horsepower
3/4
Insulation Class
H
Inverter Speed Range
Constant 1000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
P
Model Number
56H17T15528
Motor Rpm 60Hz
1800
Mounting
C-Face Removable Base
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Ul
Recognized Construction
Voltage
230/460
Weight In Lbs.
36
Marathon Motors Inverter Duty Motor, Y281, 56H17T15528, 3/4HP, 230/460V, 1800RPM, 3PH, 56C, TENV
The Max+ incorporates low rotor inertia for fast starts, stops, ad reversals. Coupled with a encoder make this useful in applications traditionally served only by servo systems. The Max+ is also suitable for all applications where up to a 1000:1 Constant Torque speed range.
